Assessment of Soil Management Practices Enhancing Soil Resilience in Small-Scale Agroecosystems: Case of Mount-Lebanon

Altmetrics

Downloads

174

Views

126

Comments

0

Submitted:

07 October 2023

Posted:

10 October 2023

You are already at the latest version

Alerts
Abstract
Soil resilience has become a central theme in research aimed at understanding the impacts of human activities on the environment and mitigating the negative effects of soil disturbance. To evaluate how soil management practices affect soil resilience, 26 small farms were studied in a mountainous district of Lebanon. Farms were categorized into conventional (C), neutral (N), and regenerative (R), based on the practices adopted including tillage, amendments, rotation, cover crops, residues management, and pest control. Common practices included intercropping (85%), residue retention (73%), cover crops (61%), and organic amendments (46%). Qualitative assessment of soil health used indicators from Latin American Society for Agroecology (SOCLA) as well as from ‘Tool for Agroecological Performance Evaluation’ of the FAO. The indicators aligned with the classification of farms into their respective C/N/R groups. The sustainability scores were 4.28 (Low) for conventional, 6.34 (Moderate) for neutral, and 7.88 (Good) for regenerative farms. Quantitative analysis determined for 15 selected farms showed significant differences in soil organic matter (1.86% C, 2.75% N, 3.32% R), soil respiration (156C, 296N, 380R mg C-CO₂. week⁻¹), and earthworm abundance/liter (2.92C, 4.24N, 5.72R). The Soil Quality Index (SQI) provided an accurate representation of the current soil health condition, with increment from 0.05, 0.27 (low), to 0.49 (good) in conventional, neutral, and regenerative farms, respectively. The research highlights that soil resilience is influenced by a combination of intricate factors, encompassing biotic interactions, as well as physical, chemical, and biological processes. Particularly in regions like the Mediterranean basin, adopting sustainable soil management practices contributes to enduring productivity while preserving the functional integrity and resilience characteristics of the soil.
Keywords:
Subject: Environmental and Earth Sciences  -   Soil Science

Introduction

Soil resilience is a dynamic characteristic that heavily relies on the condition of the soil (intrinsic and extrinsic factors) at the moment of evaluation (Corstanje et al., 2015). Defined as the “capacity of a soil to recover its structural and functional integrity after a disturbance” (Blanco-Canqui and Lal, 2010), resilience is most likely a holistic meta-function of a community, soil or an entire ecosystem, formed from all its individual qualities, in connection with ongoing processes, driven by biota interactions (Ludwig et al., 2018). Maintaining soil resilience necessitates special conservation efforts and ongoing care to create the necessary conditions (De Andrade Bonetti et al., 2017; Seipel et al., 2019). Yet, this potential is a consequence of previous and current soil management, as well as the possibility of future soil response to disturbances (Ludwig et al., 2018). In fact, practices leading to soil degradation must be neutralized by applying others leading to improvement in soil resilience (Cowie et al., 2019). As a driver for sustainable food systems, regenerative agriculture (RA) just recently gained attention (Schreefel et al. 2020). Despite the lack of a scientific and well detailed definition, RA is considered as a farming approach with potential for self-renewal and resiliency, enhancement of soil health, protection of biodiversity, improvement of soil-water dynamics, and carbon sequestration.
Moreover, increasing efforts have been aligned to restoring the ecological resilience and productivity of land through several interventions (Haddad et al., 2021). On that account, repeated annual compost additions were an advisable practice to restore or to preserve soil fertility in Mediterranean regions (Iovieno et al., 2009). This practice is particularly relevant to agricultural soils with lower levels of organic carbon compared to natural soils (Romanya and Rovira, 2011; Darwish et al., 2018). In addition, many benefits have been associated with the use of cover crops. They reduced soil erosion and runoff, improved nitrogen cycling, weed and pest control, enhanced soil quality and increased yields (Baldivieso-Freitas et al., 2018). In a study from Lebanon, oat (Avena sativa) was used as a strategic overwinter cover crop to suppress or reduce weed and enhance nutrient cycling compared to forage radish and Narbon vetch (Rouphael et al., 2019). Therefore, the adoption of sustainable practices in soil management is essential in the Mediterranean basin (Aznar-Sanchez et al., 2020), particularly, increasing organic matter content to maintain soil productivity and reduce erosion and desertification (Zdruli and Zucca, 2018).
The methods for assessing soil sustainability and resilience remain subjects of ongoing deliberation (Mizuta et al., 2021). Whether soil resilience is to be maintained or restored, it is necessary to measure or quantify it. Previous methods have been developed to quantify the resilience of soil organisms, and soil properties to disturbance from a time-series of the response (engineering resilience). Many of the metrics of resilience are based on a comparison of a function between a disturbed and a control soil (Todman et al., 2016). More precisely, the capacity for soil to withstand physical changes has been demonstrated by observing alterations in pore volume and strength during and post compaction. Additionally, resilience in terms of soil structure has been assessed by analyzing the stability and size range of soil aggregates under wet and dry conditions, as well as tracking vertical soil shifts subsequent to compaction. On the biological front, the ability of soil to bounce back has been measured by examining shifts in the short-term decomposition of plant residues, levels of dissolved organic carbon, catabolic functions, specific groups of microbial functions, and the size and activity of microbial biomass as reactions to disturbances (Gregory et al., 2009). In fact, the complexity in measuring soil resilience traces back to the multi-functionality of soils, a pivotal role in deriving resilience (Ludwig et al., 2018). Thus, a common approach is the use of scoring functions to map indicator values to a dimensionless scale reflecting their contribution to the considered soil function (Andrews et al., 2004; Vogel et al., 2019).
In Lebanon, few studies focused on the connection between soil management practices and soil resilience. Furthermore, most of the research on soil conditions has overlooked mountainous areas because of their rugged topography. However, these areas are particularly interesting because they host farmers who manage agriculture through self-sufficiency, subsistence and market-oriented approaches. Within this framework, this study investigated the soil management practices adopted by farmers in Mount-Lebanon. Based on the fact that soil resilience is a function of healthy soil, the hypothesis was that a number of management practices could be used as a scaling and sorting technique to assess soil health. Farmers were grouped under ‘Regenerative’, ‘Conventional’ and ‘Neutral’ according to the known effects of common practices on maintaining or restoring soil health. The purpose was to assess sustainability and resilience using a qualitative approach, as well as a quantitative one, the soil quality index. The objective was to find the level of agreement between the sorting technique and the classification of these mountainous agroecosystems according to the qualitative and quantitative selected indicators.

Materials and methods

Study area

The study area, located in Aley district, Mount-Lebanon governate, has a sub-humid Med climate with a mean annual precipitation of 800 to 1000 mm. The municipalities of Ain El Jdideh (33.8066ºN, 35.63028ºE; 930m asl, 133ha), Ghaboun (33.7816ºN, 35.59505ºE; 630m asl, 212ha), Maasraiti (33.74736ºN, 35.63496ºE; 505m asl, 87ha) and Ramlieh (33.74778ºN, 35.64822ºE; 650m asl; 356ha) were selected for the study. The region has a rugged topography characterized by valleys and deep clefts, with steep slopes that form drainage basins for waterways and springs (Halwani et al., 2020).
The area is semi-urbanized, cultivated mainly with rainfed and irrigated wheat, fruit trees, tobacco, and vegetables (Verner et al., 2018). Terraced land (Terric Anthrosols) is mainly used for fruit trees and distributed among hilly to mountainous landscapes dominated by limestones (Darwish et al., 2005). Soil type varies with topography, where deep Inceptisols and shallow Entisols, Cambisols and Leptisols occupy the mountain landscape, while Luvisols cover the mild steep slopes, and Fluvisols, Vertisols the flat lands. The land use pattern of the four municipalities was represented through an elaborate map (Figure 1), employing software ArcGIS pro (3.0) based on updated land cover of 2001, Sentinel image 10m. Despite a high diversity of landscape, natural vegetation and agricultural activity dominate major parts of the areas.

Qualitative assessment

Farm history and soil management practices were obtained by visiting and interviewing all 26 farmers. Respondents were selected by means of snowball sampling in a way to achieve broad geographical coverage. Only small-scale agroecosystems (0.1-1.5 ha) cultivated with vegetables and fruit trees were considered. Based on the crop seasonality, nine farmers had their land predominantly occupied by annual crops (>70% of the land cover), while six farmers grew mostly perennials.
For the soil amendment, five farmers adopted the use of manure solely with different application frequency and placement. On the contrary, eight farmers combined the use of synthetic fertilizers and manure amendment. Meanwhile, one farmer applied synthetic fertilizers only and another farmer applied composted vegetable waste and manure. Based on the intensity and frequency of soil tillage, eight farmers adopted conventional tillage practices while five farmers applied reduced tillage practices, and only two farmers resorted to no-till.
In order to classify the farms, the management practices were separated into conventional and regenerative (Table 1). Then each conventional practice was assigned a negative score (-1) while a positive one (+1) was provided to each regenerative practice. A neutral value (0) was given for concomitant ‘C’ and ‘R’ practices. Based on this, a scoring line (-5 to +5) was established. Farmers ranging between (-5 to -2) were categorized under ‘conventional’, those between (-1 to +1) under ‘neutral’, and farmers given between (+2 to +5) under ‘regenerative’. A total of 6 conventional, 11 neutral and 9 regenerative farmers were obtained.
To reduce the number of respondent farmers, five farms were randomly selected from each category. This was done using a stratified sampling method, which is a probability sampling method (Parsons, 2017). Soil health status, in these 15 agroecosystems, was assessed with soil indicators developed by Latin American Society for Agroecology (la Sociedad Cientifica Latino americana de Agroecologia = SOCLA) (Nicholls et al., 2004). But the number of soil indicators was reduced from 10 to 6 indicators (referred to as I1, I2, I3, I5, I6 and I7 in Table 2). SOCLA indicators reflected on the structure of the soil, status of soil residues, color, odor, organic matter, soil cover, presence of invertebrates and erosion. A ‘crop diversity’ indicator (I4 in Table 2) from ‘Tool for Agroecological Performance Evaluation’ (TAPE) (FAO, 2019) raised the number to seven. These indicators will be referred to, hereafter, as SOCLA.
Based on FAO’s guidelines for soil description (FAO, 2006), agroecosystems were visited in summer 2022, when the soil is dry or slightly moist. Each indicator was assigned with a score between 1 and 10 (1 being the least desirable value, 5 a moderate or threshold value and 10 the most preferred value). Status of residues (I2) was based on the abundance and heterogeneity of decomposing residues. Crop diversity (I4) was evaluated on field and illustrated using drone-based images. The indicator used to study soil cover (I5) was based on either the standing crops percentage cover of the cultivated land or dead organic residues such as mulches. The assessment of soil erosion was based on the presence and intensity of small gullies in the cultivated land and on the integrity of the stone-terraces.

Soil sampling and analysis

Soil sampling was performed according to standard methods for the near surface (0–15 cm). Five sub-samples were collected using a spade, then mixed well to obtain a composite soil sample. Samples were air-dried then sieved (<2 mm). Soil samples (15 of them) were analyzed for available phosphorus P₂O5 (mg/kg soil) measured based on Olsen method (ISO 11263:1994), exchangeable potassium K₂O (mg/kg soil) (NF X31-108:1998), total organic matter content (%) (Walkley-Black method) at the laboratory of the Lebanese Agricultural Research Institute (LARI) in Tal Al-Amara in Bekaa region.
The earthworms count took place in-situ between 12-20 of January 2023. Three soil pits (10×10×10cm) were dug in each field, followed by hand sorting. After sampling each agroecosystem, the number of the three pits was averaged. The used technique yields satisfactory results for earthworms of more than 0.2 g live weight, but it has the disadvantage of low extraction efficiency for smaller worms (Jiménez et al., 2006). Despite it being time-consuming, labor intensive, harmful to earthworms during collection and less efficient in soils with high clay content or dense root mat, this technique was beneficial because of the small sample sizes (Singh et al., 2016).
Soil respiration analysis of the 15 soil samples was obtained using the chemical titration procedure (Haney et al, 2008). For this, a pre-incubation phase consisted of wetting 25g of the dry soil (< 4 mm) up to 50% water-filled pore space, for 21 days at ambient temperature (22-25ºC) in darkness. Five replicates of each soil sample were included, in addition to a soilless control. After this, vials already attached in the jars, were filled with 10mL of NaOH (0.5N). The jars were incubated after tightly closing them with plastic tapes, ensuring that CO₂ evolved was trapped in NaOH solution. After 24 hours, 8mL of barium chloride (BaCl₂) was added to the vials and excess alkali was back titrated with hydrochloric acid (HCl 0.25N) to a phenolphthalein end point. The control was used to correct for the CO₂ in the jar. Finally, the amount of mg CO₂-C in 25g⁻¹was calculated as follows (Anderson,1982):
CO2-C (mg/25 g soil.day-1) = (VolumeControl– VolumeSoil)* M*E
M= normality of acid; E= equivalent weight. To express the data in terms of carbon, E = 6.
The results, normalized with respect to time, were expressed as C mineralized (mg/kg of soil/week).

Quantitative Assessment: Sustainable Management Assessment Framework (SMAF)

Soil management assessment framework (SMAF) was conducted using a three-step process: (1) indicator selection, (2) indicator interpretation, (3) integration into an index (Wienhold et al., 2009; Mukherjee and Lal, 2014). As part of step one, biological [soil respiration rate (mgC-CO2/d), earthworm abundance] and chemical [available phosphorus (P₂O5), exchangeable potassium (K₂O), organic matter (OM%), pH] indicators were analyzed. Step two of the SMAF consisted of the interpretations of the laboratory values (Arshad and Martin, 2002; Andrews et al., 2004) and the identification of the minimum and maximum threshold values. For soil pH (min = 4.01, max = 8.5), available phosphorus (min = 10, max = 30) and exchangeable potassium (min = 100, max = 500), these thresholds were as reported in the literature (Amacher et al., 2007). The values of OM (%) were adapted to the soil textural class, increasing from loamy (min = 1.6, max = 3.1) to clay (min = 2.1, max = 3.4) soils.
For the soil respiration rate, the maximum threshold adapted from (NRCS-USDA, 2014), was reduced from 2 000 mg C-CO₂/kg soil/week (state of high and excessive SOM content) to 1 200 mg (a state of ideal and sufficient SOM). This step was mandatory to obtain reliable classification of soil respiration rate adapted to the Mediterranean conditions. For the second bio-indicator, that is the earthworm’s abundance (density/L of soil) a minimum and maximum threshold values (min = 2, max = 5 per liter of soil) were assigned, based on experts’ opinion.
Step three of the SMAF involved the integration of all measured soil attributes into a composite index. The simple additive integration technique was used in this study (Mukherjee and Lal, 2014):
S Q I = ∑ S Q I i −     S Q I m i n S Q I m a x − S Q I m i n
Where:
SQIi= total sum of individual soil property index values
SQImin= minimum value of the soil quality index
SQImax= maximum value of the soil quality index
Soil quality index (SQI) values were distributed in five classes: very good (score: 0.80-1.00), good (0.60-0.79), moderate (0.35-0.59), low (0.20-0.34) and very low (0.00-0.19) (Mulyono et al.2019).

Statistical analysis

The collected data was tabulated using the software Microsoft Excel 2013. All statistical analyses were performed using IBM SPSS version 23.0 statistical package. The analysis of variances (ANOVA) was performed on the entire data set indicators, to compare the statistical differences between categories assigned and the mean differences were adjudged by Tukey HSD test at a Pvalue ≤ 0.05.

Results and discussion

Soil management practices

The practice implemented by most farmers (84.6%) was intercropping/mixed cropping (Figure 2). This strategy was followed by farmers in response to the economic crisis in recent years. Products diversification aimed to provide the daily supply of fruits and vegetables, to prepare preserved food for winter season, and to increase farms income. This interpretation goes in line with the finding that agricultural diversity is promoted by small farmers (Haddad et al., 2021; FAO, 2020).
The second most common practice refers to the retention of weeds and crop residues (73.1%). In previous years, some farmers applied, prior to tillage, herbicides for weed management. Following the aggravated economic situation, farmers preferred to adopt this low-cost practice. However, tillage practices were still prominent as only 26.9% of respondents adopted reduced or no-till system, referred to as conservation tillage (Figure 2). This situation is justified by the high reliance of no-till on herbicides for weed control (d’Emden et al.,2008) and by the fact that tillage is deeply rooted among many farmers (Failla et al., 2021).
Unlike tillage practices, cover crops were grown by 61.5% of farmers (Figure 2). The most likely winter crops included fava beans, peas, chickpeas, onion, garlic, chard, and some brassica crops. These are favored as cash crops as they contribute to the diversification of farm produce. As for the use of amendments (compost and manure), only 46.1% of respondents were dependent solely on them. This could be linked to their recent price increases and higher costs of transportation and application. Amendments were added every two to three years, except for mixed farms where they are applied annually. Practices requiring a significant investment were less attractive, as these small holders produce with limited resources and investments, yet they ensure the diversification of crops cultivated, finding in consistency with Dal et al. (2021).
Some practices, such as improved drip irrigation (38.5%), conservation tillage (26.9%), crop rotations (19.2%) and organic or biologic pest and disease management (11.5%), were confined to regenerative and to a lesser extent to neutral farms. Regenerative practices were weakly adopted in conventional farms, with a noticeable absence of synergism. For example, some farmers use organic amendments with varying frequency, placement, and quantities but practice improper tillage intensity. Further, most of them were dependent on furrow irrigation, while the mismanagement of irrigation could be a potential cause for soil degradation (Darwish, 2012). Another risk is soil water erosion, especially between the beginning of Autumn and the end of Spring, either because the soil is unprotected or only partially protected (Boulal et al., 2011). However, farmers growing winter cover crops manage to mitigate water erosion in winter season (Rouphael et al., 2019). Contrarily, irrigation-induced erosion is dependent on other management practices. For example, associating no-tillage with the leaving of residues lowered runoff, a key erosive agent (Boulal et al. 2011). Briefly, combining various practices can increase the profitability of sustainable practices as it can provide several synergistic benefits (Aznar-Sanchez, 2020).

Soil qualitative assessment

Sustainability of soil management was assessed using the seven indicators presented in Table 2. Soil structure (I1) assessment was dependent on the qualitative evaluation of aggregate stability (Figure 3). Low scores characterize soils with poor and powdery structure, while high scores are associated with intact aggregates. The set of images are classified based on aggregate strength (intact, crumbly, and powdery soils).
The management of residues (I2) varied between the removal of organic residues and leaving them to decompose slowly or partially. The accumulation and decomposition of litter with earthworm activity were prominent in non-tilled agroecosystems. Weeds served as a spontaneous cover in some farms, while crop residues (grape vine and lima beans) were used as an organic mulch. In some cases, weeds were chopped and left as organic mulch while in others organic residues were eliminated or burned, leaving soil bare.
Concerning soil color, odor, and organic matter (I3), low scores are associated with soils of pale color, chemical odor, and low organic matter (Figure 4-a). Moderate scores are linked with soils having light brown color, odorless and some humus content (Figure 4-b, c and d). Contrarily, good scores are given to soils that revealed high content of humus, with a dark brown color and fresh odor (Figure 4-e and f).
Next to the crop diversity (I4), soil cover (I5) and soil erosion (I6) were used as indicators. To protect soil and retain moisture in areas otherwise subject to erosion, stone-walls are built. However, land abandonment in recent decades has led to poor terrace maintenance, promoting their collapse and increasing erosion rates (Nunes et al., 2016). Despite their ecological advantage, their maintenance is an economic burden for farmers. However, to protect the integrity of the walls some farmers left grass strips over their length; or planted deep root perennials such as oregano. In particular, one farmer implemented composting, straw mulching, no-tillage, drip irrigation and introduced small ruminants to restore the land after a decade of abandonment. Conservation systems, such as no-tillage and crop-livestock integration, have been proposed to recover degraded soils (de Andrade Bonetti et al., 2017), since they increase crop residues on the soil surface.
At the field level, the scores of SOCLA indicated an increasing level of soil management sustainability from conventional (4.28), to neutral (6.34) and regenerative (7.88) farms (Table 3). The conventional category included farmers whose level of sustainability ranged between 3.57 and 5.86, the neutral category included farmers whose level of sustainability ranged between 4.71 and 7.29. Contrarily, the regenerative category included farmers whose level of sustainability ranged between 7.29 and 8.29 (Table 3). Farmers characterized as neutral maintained a balance between practices that alter soil, creating neutral disturbances that have the potential to shift either for regenerative or conventional.

Soil quantitative assessment

Soils textural classes indicated a predominance of loamy (67% of them) and clayey (33% of them) soils, while CaCO3 varied between 0.8 and 41% (10.83 ± 10.88) (data not shown). Their pH ranged between 6.60 and 7.70, with a mean value of 7.21. Based on the analysis of variance, the pH, available P₂O5, exchangeable K₂O tests did not show a difference between classes (Table 4). Exchangeable potassium content as well as the available phosphorus are directly affected by the short-term addition of mineral fertilizers by farmers, which explains the lack of differences between agroecosystems.
Only SOM, soil respiration and earthworms gave a significant difference between categories (Table 4). The highest organic matter was attained under regenerative, followed by neutral then by conventional category (Table 4). For soil respiration and earthworm counts, the means under the regenerative farms were significantly higher than in the conventional category (Table 4). In the current study, soil organic matter was a potential indicator and showed positive correlation with earthworms and soil respiration rate (C-CO₂). These more resilient agroecosystems are characterized by more active microbial communities, as suggested by the higher rates of soil microbial respiration. However, since several years are required for a noticeable positive increment after implementing conservative management approaches (Blanco-Moure et al., 2016; Darwish and Fadel, 2017), SOC is not suggested as a short-term indicator of soil health and is not always the best indicator of changes in soil management (Blanco-Moure et al., 2016).

Soil Quality Index

The Soil quality index (SQI) was established to verify the former hypothesis ‘management practices with varying degree could be used as a scaling and sorting technique of farmers’. SQI can also be used to assess soil health and resilience in different management schemes.
The results (Table 3) indicated that the lowest SQI was associated with the conventional category (0.05), followed by the neutral category (0.27), and the regenerative category (0.49). Based on the classification criteria (Mulyono et al., 2019), the conventional and neutral categories presented very low SQI, while the regenerative category a moderate one.
This actual measure of soil health expressed very low to moderate grades. Farms belonging to the conventional and neutral categories were characterized by very low soil health. Contrarily, the regenerative category was classified with moderate soil health. Conventional farms pay a first bill to achieve an intensified crop, and a second one to fight and control pests and diseases. Neutral farmers may have a greater potential to shift towards regenerative practices, yet the conditions required to step this transition is socio-economically bounded. This category may be resilient to future disturbances, but soil functions would be less efficient and consequently ecosystem services must be compromised. Regenerative farmers were environmentally driven and at the same time the healthy food supply was not totally dependent on the farm performance.
Soil management sustainability grades (SOCLA evaluation) are consistent with SQI classes. These findings are reasonably based on two scientific evidence. First, the reference document of the United Nations (UN) on the status of global soil resources stresses that most of the world’s soil resources are in fair, poor or very poor conditions (FAO, 2015). Second, Mediterranean soils specifically have been characterized by low levels of organic matter in surface layers (Romanya and Rovira, 2011; Darwish et al., 2018). Therefore in spite of numerous regenerative practices (Cowie et al., 2019), the restoration of soil functions may take decades (Pey and Dolliver, 2020). Respondent farmers were totally driven towards sustaining their livelihoods. The management practices adopted were not always efficient in improving soil health in the long-term, since the goal is to ensure soil fertility for crop production in the short-term. The varying degree of disturbance under the three farming categories is clearly observable through soil health in this study.

Conclusion

The hypothesis positing that the degree of management practices could serve as a sorting mechanism for farmers has enabled a comprehensive assessment of the impact of these practices on soil resilience. The implementation of the proposed scoring technique facilitated the classification of 26 small farms into distinct categories: neutral, regenerative, and conventional production units. This selection encompassed a diverse range of smallholding farms, ensuring a continuous and ample supply of food through crop diversity and intensification efforts aimed at offsetting income losses. Responding to economic challenges, both conventional and regenerative farming practices have placed heightened demands on soil resources. However, the implementation of synergistic management practices, particularly evident in regenerative farms, has enabled a more sustainable approach to intensification by fostering soil resilience against disturbances. On the contrary, conventional farming methods have shown limited incorporation of regenerative practices.
Comparatively, regenerative farms have demonstrated significant enhancements in soil structure and fertility, thereby facilitating improved nutrient retention, heightened crop resilience, and reduced erosion. The enhanced soil structure in regenerative farms also enables efficient water absorption and retention, thereby mitigating the risk of drought stress for cultivated crops. Further, the integration of biodiversity in regenerative farms has led to well-balanced and resilient ecosystems, marked by stable yields, reduced input costs, and elevated economic viability. Neutral farms, characterized by varying levels of soil conservation practices, contribute a crucial balance to the study. Their inclusion prevents the introduction of bias by offering a more comprehensive evaluation of diverse soil conservation strategies.
The assessment methods, encompassing the soil management practices sustainability assessment (using SOCLA) and the Composite Soil Health Index (SQI), have consistently aligned with each other, reaffirming the viability and utility of the proposed hypothesis that clusters farmers based on their impact on soil health. The soil parameter values, including organic matter percentage (OM%), soil respiration (C-CO2 mg/week), and earthworm abundance (per Liter), effectively corresponded to specific farming types. Notably, the culmination of synergistic soil management practices in regenerative farming led to a notably higher soil quality index (0.49), in contrast to the minimal value observed in conventional farms (0.05). The effectiveness of the rapid and efficient farm sorting methodology in distinguishing and evaluating soil health has been clearly established.

References

  1. Amacher M.C., O’Neil K.P. and Perry C.H. (2007). Soil vital signs: A new soil quality index (SQI) for assessing forest soil health. Fort Collins, Colorado, United States: Department of Agriculture, Forest Service, Rocky Mountain Research Station, RMRS-RP-65. [CrossRef]
  2. Anderson J. (1982). Soil respiration. In A. Page (ed). Methods of soil analysis. Part 2: Chemical and microbiological properties. Madison, Wisconsin USA: ASA and SSSA, pp. 1160 - 831-871. Agronomy Monographs (2nd edition), 9. [CrossRef]
  3. Andrews S. S., and Carrol C. R. (2001). Designing a soil assessment tool for sustainable agroecosystem management. Ecological Applications, 11(4): 1573-1585. Retrieved from http://www.jstor.org/stable/3061079. [CrossRef]
  4. Andrews S.S., Karlen D.L., and Cambardella C.A. (2004). The soil management assessment framework, a quantitative soil quality evaluation method. Soil Science Society of America Journal, 68(18). [CrossRef]
  5. Arshad M. A., and Martin S. (2002). Identifying critical limits for soil quality indicators in agro-ecosystems. Agriculture, Ecosystems & Environment, 88(2): 153–160. [CrossRef]
  6. Aznar-Sánchez J. A., Velasco-Muñoz J. F., López-Felices B., and del Moral-Torres F. (2020). Barriers and facilitators for adopting sustainable soil management practices in Mediterranean olive groves. Agronomy, 10(4): 506. [CrossRef]
  7. Baldivieso-Freitas P., Blanco-Moreno J.M., Gutiérrez-López M., Peigné J., Pérez-Ferrer A., Trigo-Aza D. and Sans F.X. (2018). Earthworm abundance response to conservation agriculture practices in organic arable farming under Mediterranean climate. Pedobiologia, 66: 58–64. [CrossRef]
  8. Blanco-Canqui H. and Lal R. (2010). Principles of soil conservation and management. Netherlands: Springer. [CrossRef]
  9. Blanco-Moure, N., Gracia, R., Bielsa, A. C. and López, M. V. (2016). Soil organic matter fractions as affected by tillage and soil texture under semiarid Mediterranean conditions. Soil and Tillage Research, 155, 381–389. [CrossRef]
  10. Boulal, H., Gómez-Macpherson, H., Gómez, J. A., and Mateos, L. (2011). Effect of soil management and traffic on soil erosion in irrigated annual crops. Soil and Tillage Research, 115–116, 62–70. [CrossRef]
  11. Cowie A. L., Waters C. M., Garland F., Orgill S. E., Baumber A., Cross R., O’Connell D., and Metternicht G. (2019). Assessing resilience to underpin implementation of Land Degradation Neutrality: A case study in the rangelands of western New South Wales, Australia. Environmental Science & Policy, 100: 37–46. [CrossRef]
  12. Corstanje, R., Deeks, L. R., Whitmore, A. P., Gregory, A. S., and Ritz, K. (2015). Probing the basis of soil resilience. Soil Use and Management, 31, 72–81. [CrossRef]
  13. D’Emden F.H., Llewellyn R.S. and Burton M.P. (2008). Factors influencing adoption of conservation tillage in Australian cropping regions. The Australian Journal of Agricultural and Resource Economics, 52(2): 169–182. [CrossRef]
  14. Dal E., Diaz-Gonzales A. M., Morales-Opazo C., and Vigani M. (2021). Agriculture sector review in Lebanon. Rome: FAO. Agricultural Development Economics Technical Study No. 12. [CrossRef]
  15. Darwish T. (2012). Assessment of the status of soil resources in Lebanon. In H. Kouyoumjian and M. Hamzé (Eds). Review and perspectives of environmental studies in Lebanon. INCAM-EU/CNRS Lebanon (pp. 328 pp.171-198). Beirut: National Council for Scientific Research.
  16. Darwish T. and Fadel A. (2017). Mapping of soil organic carbon stock in the Arab countries to mitigate land degradation. Arabian Journal of Geosciences, 10(21): 474. [CrossRef]
  17. Darwish T., Atallah T., and Fadel A. (2018). Challenges of soil carbon sequestration in the NENA region. SOIL, 4(3): 225–235. [CrossRef]
  18. Darwish T., Jooma I., Awad M., Abou Daher M., and J. Msann (2005). Inventory and management of Lebanese soils integrating the soil geographical database of Euro-Mediterranean countries. Lebanese Science Journal, 6(2): 15.
  19. De Andrade Bonetti J., Anghinoni I., de Moraes M. T., and Fink J. R. (2017). Resilience of soils with different texture, mineralogy and organic matter under long-term conservation systems. Soil and Tillage Research, 174: 104-112. [CrossRef]
  20. Failla S., Pirchio M., Sportelli M., Frasconi C., Fontanelli M., Raffaelli M. and Peruzzi A. (2021). Evolution of smart strategies and machines used for conservative management of herbaceous and horticultural crops in the Mediterranean basin: A Review. Agronomy, 11(1): 106. [CrossRef]
  21. FAO (2006). Guidelines for soil description (Fourth edition). Rome: Food and Agriculture Organization of the United Nations. ISBN 92-5-105521-1.
  22. FAO (2019).TAPE Tool for Agroecology Performance Evaluation: Process of development and guidelines for application. Test version (2019). Rome. ISBN 978-92-5-132064-8.
  23. FAO (2020). Special Report - FAO Mission to Assess the Impact of the Financial Crisis on Agriculture in the Republic of Lebanon. Rome. [CrossRef]
  24. FAO and ITPS (2015). Status of the world’s soil resources (SWSR) – technical summary. Rome: Food and Agriculture Organization of the United Nations and Intergovernmental Technical Panel on Soils.
  25. Gregory, A. S., Watts, C. W., Griffiths, B. S., Hallett, P. D., Kuan, H. L., and Whitmore, A. P. (2009). The effect of long-term soil management on the physical and biological resilience of a range of arable and grassland soils in England. Geoderma, 153(1–2), 172–185. [CrossRef]
  26. Griffiths B.S., Hallett P.D., Kuan H.L., Pitkin Y. and Aitken M.N. (2005). Biological and physical resilience of soil amended with heavy metal-contaminated sewage sludge. European Journal of Soil Science, 56(2): 197–206. [CrossRef]
  27. Haddad F.F., Ariza C. and Malmer A. (2021). Building climate-resilient dryland forests and agrosilvopastoral production systems: An approach for context-dependent economic, social, and environmentally sustainable transformations. Rome: FAO. Forestry working paper No. 22. [CrossRef]
  28. Halwani D. A., Jurdi M., Abu Salem F. K., Jaffa M. A., Amacha N., Habib R. R., and Dhaini H. R. (2020). Cadmium health risk assessment and anthropogenic sources of pollution in Mount-Lebanon springs. Exposure and Health, 12(2): 163–178. [CrossRef]
  29. Haney R. L., Brinton W. H., and Evans E. (2008). Estimating soil carbon, nitrogen, and phosphorus mineralization from short-term carbon dioxide respiration. Communications in Soil Science and Plant Analysis, 39(17–18): 2706–2720. [CrossRef]
  30. Iovieno P., Morra L., Leone A., Pagano L., and Alfani A. (2009). Effect of organic and mineral fertilizers on soil respiration and enzyme activities of two Mediterranean horticultural soils. Biology and Fertility of Soils, 45(5): 555–561. [CrossRef]
  31. Jiménez J. J., Lavelle P., and Decaëns T. (2006). The efficiency of soil hand-sorting in assessing the abundance and biomass of earthworm communities. Its usefulness in population dynamics and cohort analysis studies. European Journal of Soil Biology, 42: S225–S230. [CrossRef]
  32. Ludwig M., Wilmes P., and Schrader S. (2018). Measuring soil sustainability via soil resilience. Science of The Total Environment, 626: 1484–1493. [CrossRef]
  33. Mizuta, K., Grunwald, S., Cropper, W. P., & Bacon, A. R. (2021). Developmental History of Soil Concepts from a Scientific Perspective. Applied Sciences, 11(9), 4275. [CrossRef]
  34. Mukherjee A., and Lal R. (2014). Comparison of soil quality index using three methods. PLoS ONE, 9(8): e105981. [CrossRef]
  35. Mulyono A., Suriadikusumah A., Harriyanto R. and Djuwansah M. (2019). Soil quality under agroforestry trees pattern in Upper Citarum Watershed, Indonesia. Journal of Ecological Engineering, 20(1): 203–213. [CrossRef]
  36. Nicholls C. I., Altieri M. A., Dezanet A., Lana M., Feistauer D., and Ouriques M. (2004). A rapid, farmer-friendly agroecological method to estimate soil quality and crop health in vineyard systems. Biodynamics, 9: 33-40.
  37. NRCS-USDA (2014). Soil health educators guide. Retrieved January 30, 2023, from Natural Resources Conservation Services. U.S. Department of agriculture: https://usda.gov/.
  38. Nunes, J. P., Bernard-Jannin, L., Rodríguez Blanco, M. L., Santos, J. M., Coelho, C. D. O. A., and Keizer, J. J. (2018). Hydrological and Erosion Processes in Terraced Fields: Observations from a Humid Mediterranean Region in Northern Portugal: Hydrology and Erosion in a Humid Mediterranean Terraced Field. Land Degradation & Development, 29(3), 596–606. [CrossRef]
  39. Oldfield E. E., Bradford M. A., and Wood S. A. (2019). Global meta-analysis of the relationship between soil organic matter and crop yields. SOIL, 5(1): 15–32. [CrossRef]
  40. Parsons V. L. (2017). Stratified sampling. In N. Balakrishnan, T. Colton B. Everitt W. Piegorsch F. Ruggeri and J. L. Teugels (Editors), Wiley StatsRef: Statistics Reference Online (1st ed., pp. 1–11). Wiley. [CrossRef]
  41. Pey, S. L., and Dolliver, H. A. S. (2020). Assessing soil resilience across an agricultural land retirement chronosequence. Journal of Soil and Water Conservation, 75(2), 191–197. [CrossRef]
  42. Raclot D., Le Bissonnais Y., Annabi M., Sabir M., and Smetanova A. (2018). Main issues for preserving Mediterranean soil resources from water erosion under global change: Mediterranean soil resources under global change. Land Degradation & Development, 29(3): 789–799. [CrossRef]
  43. Rouphael S., El Mekdad F., Mouawad A., Mjallal M., Touma E., El Hajj S., Hajj A., and Atallah T. (2019). Performance of overwinter cover crops in coastal Lebanon. Lebanese Science Journal, 20(1): 89–103. [CrossRef]
  44. Schreefel L., Schulte R. P. O., de Boer I. J. M., Schrijver A. P., and van Zanten H. H. E. (2020). Regenerative agriculture – the soil is the base. Global Food Security, 26: 100404. [CrossRef]
  45. Seipel T., Ishaq S. L., and Menalled F. D. (2019). Agroecosystem resilience is modified by management system via plant–soil feedbacks. Basic and Applied Ecology, 39: 1–9. [CrossRef]
  46. Singh J., Singh S., and Vig A. P. (2016). Extraction of earthworm from soil by different sampling methods: A review. Environment, Development and Sustainability, 18(6): 1521–1539. [CrossRef]
  47. Todman L.C., Fraser F.C., Corstanje R., Deeks L.K., Harris J.A., Pawlett M., Ritz K. and Whitmore A.P. (2016). Defining and quantifying the resilience of responses to disturbance: a conceptual and modelling approach from soil science. Scientific Reports, 6(1): 28426. [CrossRef]
  48. Verner D., Ashwill M., Christensen J., Mcdonnell R., Redwood J., Jomaa I., Saade M., Massad R., Chehade A., Bitar A., and Treguer D. (2018). Droughts and agriculture in Lebanon: causes, consequences, and risk management. Washington DC: World Bank Group. [CrossRef]
  49. Vogel H.J., Eberhardt E., Franko U., Lang B., Ließ M., Weller U., Wiesmeier M., and Wollschläger U. (2019). Quantitative evaluation of soil functions: potential and state. Frontiers in Environmental Science, 7: 164. [CrossRef]
  50. Wienhold B.J. Karlen D.L. Andrews S.S. and Stott D.E. (2009). Protocol for indicator scoring in the soil management assessment framework (SMAF). Renewable Agriculture and Food Systems, 24(4): 260. [CrossRef]
  51. Zdruli, P. and Zucca, C. (2018). Maintaining soil health in dryland areas. In: Managing soil health for sustainable agriculture (Ed. Reicosky). Burleigh and Dods Science Publishing, Cambridge CB22 3HJ UK. ISBN-13: 9781786761927.
Preprints 87210 g001
Figure 1. Map illustrating the land use pattern in the four municipalities of the study region.
Figure 1. Map illustrating the land use pattern in the four municipalities of the study region.
Preprints 87210 g001
Preprints 87210 g002
Figure 2. Distribution and frequency of regenerative soil management practices adopted by respondent farmers (n=26).
Figure 2. Distribution and frequency of regenerative soil management practices adopted by respondent farmers (n=26).
Preprints 87210 g002
Preprints 87210 g003
Figure 3. Soil aggregates visualization associated with different management practices and soil texture. Scores classified based on intact, friable, crumble and powdery soils.
Figure 3. Soil aggregates visualization associated with different management practices and soil texture. Scores classified based on intact, friable, crumble and powdery soils.
Preprints 87210 g003
Preprints 87210 g004
Figure 4. Visual illustration of soil samples used as a benchmark for the assessment of soil color, odor, and organic matter indicator.
Figure 4. Visual illustration of soil samples used as a benchmark for the assessment of soil color, odor, and organic matter indicator.
Preprints 87210 g004
Table 1. List of regenerative and conventional practices used to score the 26 studied farms into a conventional/neutral/regenerative class.
Table 1. List of regenerative and conventional practices used to score the 26 studied farms into a conventional/neutral/regenerative class.
Regenerative practices Conventional practices
Conservation (No-tillage) or reduced Excessive tillage practices
Compost amendments/green manure Synthetic fertilizers
Crop rotation No crop rotation
Intercropping/mixed cropping Monoculture
Cover crops No cover crops
Improved irrigation technique Furrow irrigation
Organic or biological pest and diseases treatment Pesticide treatment (herbicides, insecticides, etc.)
Mixing crop and weed residues with soil, usage as organic mulch, or in composting Burning or eliminating organic residues
Table 2. Soil quality indicators (I) with corresponding characteristics and estimated values used to obtain the SOCLA evaluation. Indicator I4 was adapted from the FAO (2019). Indicators I1, I2, I3, I5, I6 and I7 correspond to the SOCLA evaluation of soils.
Table 2. Soil quality indicators (I) with corresponding characteristics and estimated values used to obtain the SOCLA evaluation. Indicator I4 was adapted from the FAO (2019). Indicators I1, I2, I3, I5, I6 and I7 correspond to the SOCLA evaluation of soils.
Indicator Established value Characteristics Field score
Structure
I1 		1-3 Loose soil, powder exhibiting no visible aggregates
4-6 Small number of aggregates, readily breakable
7-10 Well-formed aggregates, difficult to break
Status of residues
I2 		1-3 Organic residues decomposing slowly
4-6 Presence of last years’ decomposing residues
7-10 Heterogenous nature of residues, most are well decomposed
Color, odor, and organic matter
I3 		1-3 No presence of humus with pale and chemical odor
4-6 Moderate amount of humus, light brown, odorless
7-10 Abundant humus, fresh odor, dark brown
Crop diversity
I4 		1-3 Monoculture covering 80% of cultivated area
4-6 Two to three crops/tree species
7-10 More than three crops and varieties
Soil cover
I5 		1-3 No crops, bare soil
4-6 Vegetative cover or residues covering less than 50% of land
7-10 Vegetative cover or residues covering more than 50% of land
Erosion
I6 		1-3 Severe presence of small gullies or fallen stone walls
4-6 Evident but low erosion signs
7-10 No visible signs of erosion
Invertebrates activity
I7 		1-3 No earthworms
4-6 Few earthworms
7-10 Abundant presence of earthworms
Table 3. Scores of the SOCLA tool (based on 7 indicators) and of the soil quality indicator (SQI) referring to the management of 15 farms classified as conventional, neutral or regenerative.
Table 3. Scores of the SOCLA tool (based on 7 indicators) and of the soil quality indicator (SQI) referring to the management of 15 farms classified as conventional, neutral or regenerative.
Farm category
Conventional Neutral Regenerative
SOCLA Mean 4.28 6.34 7.88
Standard
deviation		 0.82 1.05 0.39
Minimum 3.57 4.71 7.29
Maximum 5.86 7.29 8.29
Evaluation
 Low
(3-4.9)		 Moderate
(5-6.9)		 Good
(7-8)
SQI Mean 0.05 0.27 0.49
Standard
deviation		 0.15 0.15 0.11
Minimum - 0.15 0.09 0.39
Maximum 0.29 0.49 0.67
Evaluation
(Mulyono et al. 2019)		 Very low (<0.38) Moderate (>0.44)
Table 4. Mean distribution and standard deviation (std) of measured soil parameters (available phosphorus, exchangeable potassium, soil organic matter and soil respiration) under the three categories: C: conventional, N: neutral and R: regenerative farmers.
Table 4. Mean distribution and standard deviation (std) of measured soil parameters (available phosphorus, exchangeable potassium, soil organic matter and soil respiration) under the three categories: C: conventional, N: neutral and R: regenerative farmers.
Mean ± std
CLASS pH
Av. P2O5
(mg/kg soil)
Ex. K2O (mg/kg soil)
OM %
C-CO2 mg.25g/d
Earthworm (#/L)
C 7.2±0.27 83.6±51.5 235.2±100 1.86±0.79ᵇ 156.2±70.4ᵇ 2.9±1.86ᵇ
N 7.1±0.37 171.6±17.1 510.2±312 2.75±0.72 ͣᵇ 295.7±109.3 ͣ 4.2±1.52 ͣᵇ
R 7.3±0.27 170.1±108.2 507.8±134 3.32±0.54 ͣ 380.5±56.5 ͣ 5.7±0.80 ͣ
Different letters indicate significant differences at significance level P<0.05 between values in columns for each parameter.
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.
Copyright: This open access article is published under a Creative Commons CC BY 4.0 license, which permit the free download, distribution, and reuse, provided that the author and preprint are cited in any reuse.
Prerpints.org logo

Preprints.org is a free preprint server supported by MDPI in Basel, Switzerland.

facebook logotwitter logolinkedin logo
MDPI Initiatives
Important Links
Subscribe

Disclaimer

Terms of Use

Privacy Policy

© 2024 MDPI (Basel, Switzerland) unless otherwise stated
