Use of Light Emitting Diodes on the In Vitro Rooting of Apple Tree Rootstocks

Altmetrics

Downloads

98

Views

56

Comments

0

Submitted:

22 October 2024

Posted:

23 October 2024

Read the latest preprint version here

Alerts
Abstract

This study presents a novel investigation into the use of Light Emitting Diodes (LEDs) for the in vitro rooting of 'Marubakaido' and 'M9' apple tree rootstocks, marking the first time this approach has been reported in the literature. The research compares four different light sources: blue LED (450 nm), red LED (660 nm), a combination of red and blue LEDs, and traditional fluorescent lamps as a control. Mini-cuttings were inoculated in Murashige & Skoog (MS) medium with reduced nutrient concentrations and supplemented with indoleacetic acid (IAA) and sucrose. The explants were incubated under controlled conditions for 30 days, allowing for a thorough evaluation of the effects of different light sources on various growth metric. The study found that blue LEDs significantly increased dry mass accumulation in 'Marubakaido' seedlings compared to both red LEDs and fluorescent lamps, demonstrating the effectiveness of LEDs in promoting plant growth. Utilizing LEDs not only enhances seedling development but also offers economic benefits over fluorescent lamps. LEDs are known for their high luminous efficiency, low energy consumption, and long lifespan, which can lead to reduced operational costs in plant production systems. This research not only contributes to the understanding of light effects on plant tissue culture but also suggests that the combination of blue and red LEDs can serve as a viable alternative to fluorescent lamps, potentially transforming practices in the field of horticulture and plant propagation.

Keywords:
Subject: Biology and Life Sciences  -   Horticulture

1. Introduction

Apples are the most widely grown fruit in temperate climate regions, leading in both cultivated area and consumption volume. [1] Brazil is a major player in the global apple industry, producing approximately 1.38 million tons of apples annually, with 6.9% of this production being exported. [2,3] Apple cultivation ranks among the country's top six fruit crops, predominantly grown in the southern regions, including the municipalities of Vacaria in Rio Grande do Sul, Fraiburgo and São Joaquim in Santa Catarina, and Palmas in Paraná. [4,5]
In the realm of apple cultivation, rootstocks play a crucial role. They are employed for various purposes such as reducing plant vigor, providing resistance to pests and diseases, adapting to different soil conditions, inducing early fruiting, and enhancing orchard productivity. In recent decades, advancements in clonal rootstocks developed through genetic improvement have revolutionized the apple production chain. [6,7,8,9]
In Brazil, the predominant rootstocks are the dwarf M.9, the semi-vigorous M-7 and Marubakaido with M.9 interstock, and the vigorous Marubakaido. [10] The 'M9' rootstock is renowned for its dwarfing characteristics and resistance to crown rot. [10,11] It promotes early fruiting and enhances fruit productivity and quality. [12] Meanwhile, the 'Marubakaido' rootstock is recognized for its vigor and resistance to crown rot and woolly aphid. [13]
Traditionally, apple rootstocks are propagated by stool layering. [14,15] This method is slow, yields low output, is labor-intensive, and requires extensive physical space. [14,15,16] Additionally, it may inadvertently propagate materials with phytosanitary issues [17,18]
In vitro vegetative propagation has been researched to produce vegetative material for apples, [16,19] aiming at mass multiplication of cultivars and production of pathogen-free plants. [15] Also known as micropropagation, this technique involves the true-to-type reproduction of genetically valuable plants through the cultivation of plant segments in an artificial medium under aseptic conditions. [20,21,22,23]
High mortality rates of seedlings during the acclimatization phase are common in in vitro propagation systems. [20,21,22,23] Therefore, strategies that modify the environment, especially during the final stages of micropropagation, are necessary to make the seedlings more robust and improve their survival in subsequent stages. [24,25,26] To enhance the efficiency of in vitro propagation techniques, factors such as temperature, humidity, ventilation, and light should be optimized. [27] Among these, light is the most important factor, capable of significantly regulating plant growth and development. [28]
In vitro plant growth rooms are typically equipped with artificial light sources, mainly fluorescent lamps. [29] However, fluorescent lamps have undesirable characteristics such as high energy consumption and heat generation, along with varied wavelength peaks, some of which are not necessary for seedling development. [28]
Light-emitting diodes (LEDs) were introduced in 1960 for plant production in closed systems. From 1960 to 2024, significant advancements were made in the architecture, construction, and enhancement of these artificial light sources. In 1961, the first infrared LEDs were patented. LEDs are known for their high efficiency, high luminous intensity, low-intensity discharge of far-red and red light, and broad wavelength spectrum, which includes ultraviolet (250–380 nm), visible light (380–760 nm), and infrared light (760–1000 nm). [30]
Light Emitting Diodes (LEDs) are being evaluated and have shown satisfactory results in plant tissue culture. [28] LEDs provide specific peaks within the range most favorable to plants, [31] and allow for the precise selection of desired wavelengths. [32] They also offer other advantages, such as high luminous efficiency with minimal heating, long lifespan, absence of heavy metals, and low energy consumption. [28]
Several studies have been conducted to investigate the effects of monochromatic lights, either alone or in combination (two or more colors), on the growth and morphogenesis of a wide variety of in vitro-cultivated seedling species. [28] According to these studies, various characteristics are affected, such as vegetative seedling growth, [33] the formation of photosynthetic pigments, [27,34] and stomatal development, among others. [35,36]
This study aimed to evaluate the effect of using LEDs as light sources on the in vitro rooting of apple rootstocks of the Marubakaido and M9 cultivars.

2. Materials and Methods

Minicuttings approximately 15 mm in length from in vitro pre-established seedlings of the Marubakaido and M9 apple rootstock cultivars were used as explants. Both were obtained from in vitro culture stocks spanning five generations of clonal rootstock cultivations originating from a living collection.
The experiments were conducted in a completely randomized design with four treatments. The treatments consisted of four lighting sources: blue LED (450 nm), red LED (660 nm), red + blue LED (10 diodes of 660 nm and 4 diodes of 450 nm), and fluorescent lamp (control). For the Marubakaido cultivar seedlings, variables such as height, number of leaves and roots, fresh and dry mass of the aerial part and roots, and chlorophyll and carotenoid content were evaluated. Five replications of eight seedlings each were used. For the M9 cultivar seedlings, stomatal density and size were evaluated using ten replications.
The culture medium used was MS [37] with half the concentration of macronutrients and micronutrients, and iron chelate (FeEDTA) and ethylenediaminetetraacetic acid (EDTA), supplemented with 1.0 mg/L IAA and 30.0 g/L sucrose.
Stock solutions were prepared according to Murashige & Skoog [37] (Table 1) using analytically pure reagents and pipetted into a flask containing deionized water (30% of the total volume of the medium to be prepared). The volumes used for the preparation of one liter of culture medium were: 25.0 mL of macronutrient solution, 2.5 mL of micronutrient solution, 5.0 mL of FeEDTA, 5.0 mL of vitamins and amino acids, and 10.0 mL of IAA. Sucrose (30.0 g) was then added. The pH of the chemical preparation was adjusted to 5.8, and 6.0 g of agar and deionized water were added to reach the pre-established total volume, followed by boiling in a microwave oven.
The culture medium was distributed in 6.0 mL aliquots into 50 cm³ test tubes. The tubes were sealed with 7.0 x 7.0 cm aluminum foil and sterilized by autoclaving at 121°C and 1.05 kg/cm² pressure for 15 minutes.
After disinfecting the Laminar Flow Hood with 70% ethanol and sterilizing it with UV light (100 to 280 nm) for 20 minutes, the explant inoculation process began. Using tweezers and scissors, the mini-cuttings were isolated and inoculated into the culture medium vertically in the tubes, ensuring each tube contained one explant.
In the growth room, the shelves were equipped with two tubular lamps each. The first shelf was equipped with blue LED lamps (Tecnal®, Tec-Lamp, 14 diodes of 450 nm, 28 W, 99.6 ± 20.4 µmol m-² s-¹, 900 mm), the second with red LED lamps (Tecnal®, Tec-Lamp, 14 diodes of 660 nm, 28 W, 82.2 ± 13.0 µmol m-² s-¹, 900 mm), the third with red and blue LED lamps (Tecnal®, Tec-Lamp, 10 diodes of 660 nm and 4 diodes of 450 nm, 28 W, 81.8 ± 14.3 µmol m-² s-¹, 900 mm), and the last with fluorescent lamps (Osram®, T8 FO 32W/640, 24.4 ± 4.4 µmol m-² s-¹, 1200 mm). Light-blocking curtains (Blackout®) were installed at the ends to prevent interference from other light sources.
The tubes containing the inoculated explants were transferred to the Growth Room, where they remained for 30 days under controlled environmental conditions: a temperature of 25 ± 2°C, a 16-hour photoperiod, and different lighting conditions. The environmental factors were monitored throughout the rooting period of the seedlings.
After removing the plant material from the test tubes, evaluations were conducted for height, number of leaves and roots, and fresh and dry mass of shoots and roots. Height was measured using a caliper, recording the distance between the collar region and the insertion of the last leaf. The number of leaves and roots was then counted. The shoots and roots were separated and weighed to obtain the fresh mass, then placed separately in paper bags and transferred to an oven for drying at 60°C. After 96 hours, the dry mass was measured.
Samples (approximately 150 mg of fresh mass) were randomly collected and ground in a mortar with a pestle. The macerate was filtered, and ethanol (NEON®, 95%) was added to make up 50 mL in a volumetric flask, previously wrapped with aluminum foil. The extract was analyzed using a UV-VIS spectrophotometer (Varian Cary 50) with readings at 664 nm for chlorophyll a, 648 nm for chlorophyll b, and 470 nm for carotenoids. The absorbance values obtained were substituted into LICHTENTHALER's equations (1987), and the final values were expressed in milligrams per gram of fresh mass (mg/g).
To evaluate the density (number of stomata per mm²) and average area (µm²) of stomata, the technique of impression with clear nail polish, adapted from the universal instant adhesive impression technique (Superbonder®). The leaves of the seedlings were placed on a small layer of clear nail polish on a glass slide, with the abaxial surface in contact with the substance. After complete drying, the leaves were removed and discarded.
The slides were focused at 40x magnification on an optical microscope (AAKER®) and the images were captured using a scientific camera (Opticam®) with a resolution of 14.0 MP. The stomatal density and average area were obtained by counting the number of stomata and measuring the area of each stoma in a 0.0536 mm² image using ToupView 3.7 software.

2.1. Statistical Analysis

The data obtained from the four independent treatments were assessed for normality and homogeneity using the Shapiro-Wilk test and Bartlett’s test, respectively. When the data were both homogeneous and normally distributed, the four treatments were compared using a one-way ANOVA (a parametric test). If the data were not normally distributed, the treatments were compared using the Kruskal-Wallis test (a nonparametric test). [38] Hypothesis testing (one-way ANOVA and Kruskal-Wallis) was carried out at a 95% confidence level (p-value < 0.05). The Tukey test was used as the post hoc test following the one-way ANOVA, while the Dwass-Steel-Critchlow-Fligner pairwise comparisons were used with the Kruskal-Wallis test. All post hoc tests were conducted with a 95% confidence interval. These tests were performed using JAMOVI (version 2.3.28). [39] Boxplots with violin plots, created using JASP (version 0.18.3.0), were used to represent the data from the four independent treatments. [40,41,42] Principal component analysis (PCA) was conducted using JAMOVI’s MEDA plugin. [43]

3. Results and Discussion

The vegetative growth parameters measured for Marubakaido apple rootstock seedlings which were grown using LEDs and a florescent lamp, were provided in Table 1. Figure 1 shows the Seedlings of the Marubakaido apple rootstock cultivar obtained using LEDs and a fluorescent lamp (control).

3.1. Height

There were no differences between the four treatments for the height of Marubakaido apple rootstock seedlings. The four treatments provided equivalent heights (Figure 2). The Shapiro-Wilk test showed that the data was not normally distributed (p-value < 0.001) Then, the Kruskal-Wallis test showed that heights obtained using the four treatments were equivalent (p-value = 0.304).

3.2. Dry and Fresh Mass of the Aerial Parts

The treatments with blue LED and the combination of red + blue LED resulted in a significant increase in both fresh and dry mass compared to the treatment with fluorescent lamps (Table 2).
Means followed by the same letter in the column do not differ statistically according to Tukey's test at 5%. ns: not significant according to Tukey's test at 5%.
The fresh mass of the arial parts obtained using LED treatments provided larger fresh mass than the control (fluorescent lamp). Between the LED treatments the blue LED provided larger fresh mass of the aerial parts than the other two LED treatments (Figure 3). The Shapiro-Wik test showed that the data was normally distributed (p-value = 0.600), the Bartlett’s test showed that variances were equivalent (p-value = 0.904), the one-way ANOVA showed that the four treatments provided different fresh mass of the aerial parts (p-value < 0.001). The Tukey test showed that red LED and red + blue LED treatments provided equivalent dry masses of the aerial parts (p-value = 0.383).
The dry mass of the aerial parts obtained using LED treatments provided larger masses than the control (Figure 4). The Shapiro-Wik test showed that the data was normally distributed (p-value = 0.615), the Bartlett’s test showed that variances were equivalent (p-value = 0.432), the one-way ANOVA showed that the four treatments provided different dry mass of the aerial parts (p-value < 0.001). The Tukey test showed that red LED treatment was equivalent to the red + blue LED treatment (p-value = 0.255). All treatments carried out using LED provided larger dry masses than the control.
The light emission peaks in the blue and red wavelengths coincide with the maximum absorption of chlorophylls, thereby allowing photosynthesis to occur with maximum efficiency. [44,45] This effect may be related to the greater accumulation of dry mass in the seedlings exposed to blue LED and red + blue LED compared to those exposed to fluorescent lamps.
The results of the current experiment indicate that blue light (450 nm wavelength) positively influences the development of the aerial parts of Marubakaido apple rootstock seedlings. Beyond its role in photosynthesis, light is essential for regulating growth and morphogenesis processes. Plant responses to blue light are attributed to the presence of pigments such as phytochromes, cryptochromes, and phototropins. When stimulated, these pigments control the expression of certain genes, stomatal opening, flowering, and other processes. [46] Blue light-induced stomatal opening enhances gas exchange during photosynthesis, directly impacting crop productivity. [45]
A similar effect was found by Shin et al. [46] when cultivating orchids in vitro. They observed that seedlings grown under a combination of red and blue LEDs exhibited higher fresh and dry leaf mass compared to those grown under fluorescent lamps. In studies on Gossypium hirsutum L., Li et al. [47] found that the red and blue light combination also resulted in greater fresh and dry seedling mass than fluorescent lamps. The increase in fresh and dry mass can help seedlings survive the acclimatization phase, [48] which is the most critical stage in micropropagation systems due to the high mortality rate of seedlings.
When used alone, red LED light (660 nm) produced results inferior to blue light but comparable to fluorescent lamps and the red + blue LED combination in terms of fresh and dry mass of the aerial part (Table 2). This indicates that red LEDs at 660 nm can also be used for in vitro cultivation of Marubakaido apple rootstock.
Similarly, Lin et al. [34] revealed that fluorescent lamps and red LEDs were less efficient than blue LEDs, leading to lower shoot formation and dry mass in Dendrobium officinale explants cultivated in vitro. Liu et al. [49] observed that Platycodon gradiflorum seedlings showed greater dry mass increase when grown under blue LEDs compared to red LEDs. Red light may induce starch accumulation in chloroplasts, which can inhibit photosynthesis in plants. [36] According to SÆBØ et al. [50] one response induced by exposure to red light is the reduction of photoassimilate translocation from leaves to other parts of the plant. This can lead to starch accumulation in chloroplasts and indirectly reduce the photosynthetic rate, potentially explaining the lower dry mass production in seedlings exposed to red light compared to blue light.

3.3. Roots Dry and Fresh Mass

The roots dry mass obtained using LED treatments were equivalent to those obtained using the control (Figure 5). The Shapiro-Wik test showed that the data was not normally distributed (p-value = 0.001), the Bartlett’s test showed that variances were not equivalent (p-value = 0.01), the Kruskal-Wallis test showed that the four treatments provided equivalent results (p-value < 0.014). The p-value provided by the Kruskal-Wallis test was smaller than 0.05, but he Dwass-Steel-Critchlow-Fligner pairwise comparisons (Table 4) confirmed that results obtained using LEDs were equivalent from those obtained using the control.
The roots fresh mass obtained using LED treatments were equivalent to those obtained using the control (Figure 6). The Shapiro-Wik test showed that the data was normally distributed (p-value = 0.501), the Bartlett’s test showed that variances were equivalent (p-value = 0.629), the one-way ANOVA showed that the four treatments provided equivalent results (p-value < 0.835).

3.4. Number of Leaves and Roots

The number of leaves obtained using LED treatments were equivalent to those obtained using the control (Figure 7). The Shapiro-Wik test showed that the data was not normally distributed (p-value = 0.001), the Bartlett’s test showed that variances were not equivalent (p-value = 0.012), the Kruskal-Wallis test showed that the four treatments provided equivalent results (p-value < 0.213).
The number of roots obtained using LED treatments were equivalent to those obtained using the control (Figure 8). The Shapiro-Wik test showed that the data was normally distributed (p-value = 0.134), the Bartlett’s test confirmed data homogeneity (p-value = 0.999), the one-way ANOVA test showed that the four treatments provided equivalent results (p-value < 0.127).
Plant height, number of leaves, number of roots, and fresh and dry root mass were not affected by the different light sources (Table 2). According to Moon et al. [27] light quality can influence plant morphology. For example, plant height can be promoted or inhibited depending on the different interactions between blue and red-light receptors and phytochromes. [51]
A similar result was obtained by Li et al. [47] when they cultivated Brassica napus L. in vitro. The researchers observed that the stem length of seedlings treated with LEDs was comparable to those treated with fluorescent lamps.
The wavelength of light can affect the rooting of in vitro seedlings, varying according to the cultivated species. [27] A study by Chée [52] showed that blue LEDs had more promising effects on the rooting of grapevine seedlings compared to red LEDs. On the other hand, Moon et al. [27] observed that the number of roots in Tripterospermum japonicum was induced by fluorescent lamps and the red + blue LED combination but inhibited by isolated red and blue LEDs. Shin et al. [46] reported that the fresh and dry root masses of in vitro orchids increased when grown under the red + blue LED combination. However, Jao et al. [53] found that Zantedeschia jucunda seedlings subjected to fluorescent lamps had greater dry root mass formation than those treated with LEDs.

3.5. Principal Component Analysis (PCA)

Finally, an analysis of vegetative growth was conducted using PCA, [54,55] The score plot would be used to observe correlations and trends of the data. [56,57,58,59] The score plot (Figure 9) shows that number of roots, root fresh mass, and height were correlated variables samples places in the top of the right side had larger values of those parameters than samples placed in the left side. It also shows that samples placed on the right side had larger number of leaves, fresh mass of the aerial parts, dry mass of aerial parts, and roots dry mass than samples placed in the left side.
The loading plot (Figure 10) shows that Marubakaido apple rootstock samples that had larger vegetative growth were placed in the right side, while samples that had smaller vegetative growth were placed in the left side. Most of the samples placed on the right side were growth under blue LED, while most of the samples placed at the left side were controls. It showed that LED lights were more efficient than control.

3.6. Chlorophyll a, b, Total (a + b) and Carotenoids Content

Treatment with fluorescent lamps resulted in higher concentrations of chlorophylls a, b, total chlorophyll (a+b), and carotenoids in leaf samples compared to LED treatments. The different LED wavelengths did not show significant differences among themselves for pigment formation (Table 5). Jao et al. [53] cultivated Zantedeschia jucunda in vitro and reported that fluorescent lamps yielded more promising results for chlorophyll formation than LED treatments. Another study by Moon et al. [27] showed that chlorophyll content in Tripterospermum japonicum was higher when seedlings were treated with fluorescent lamps and red + blue LED combinations but inhibited under isolated red and blue LEDs. However, Shin et al. [46] observed that in vitro-cultivated Doritaenopsis plants under the red + blue LED combination had higher chlorophyll and carotenoid content than those grown under fluorescent lamps. These studies indicate that the synthesis of chlorophylls and carotenoids in plants exposed to different light sources may vary depending on the species.
Although carotenoids are known for their important role in protecting organisms from light-induced damage, [60,61] both carotenoids and chlorophylls are involved in energy capture by plants. [62,63,64] Light wavelengths play a crucial role in regulating photosynthesis, with blue and red LEDs being the most used for seedling growth. Their wavelengths, approximately 460 nm and 660 nm, respectively, represent the ranges of highest photosynthetic efficiency. [28]
Fluorescent lamps have wavelength peaks ranging from 350 to 750 nm in the electromagnetic spectrum, emitting light in a broad range of colors, many of which are unnecessary for seedling development. [28] Plants exposed to white light preferentially absorb light in the blue, red, and part of the green spectra. [65,66]
Alvarenga et al. [67] showed that green LEDs induced greater synthesis of chlorophylls a, b, and total (a+b) and carotenoids in Achillea millefolium seedlings compared to blue and red LEDs. According to the same authors, the increase in pigment levels in plants when exposed to green light may be associated with stress in response to a lack of photosynthetically active light.

3.7. Density and Average AREA of Stomata

Despite having higher chlorophyll and carotenoid content, seedlings treated with fluorescent lamps did not show an increase in the photosynthetic rate, as the dry mass accumulation was lower with fluorescent lamps than with blue LEDs and the red + blue LED combination. This result may be due to the provision of light in the wavelengths of interest for photosynthesis, which is more favorable for seedlings in the case of LEDs.
Optical microscopy images of the abaxial surface of leaf samples showed that the density and average area of stomata were not affected by the different light sources (Table 6). A similar result was obtained by Li et al. [47] when they observed the development of Brassica napus L. seedlings subjected to blue LEDs and the red + blue LED combination. The researchers reported that the number of stomata in these seedlings did not differ from those treated with fluorescent lamps. Figure 11 shows the stomata of the abaxial face of leaf samples of ‘M9’ apple tree rootstock obtained using LEDs and a fluorescent lamp.
In contrast, Li et al. [47] found that the stomatal density of Gossypium hirsutum L. seedlings was stimulated by red LEDs and inhibited by blue LEDs and the red + blue LED combination. However, the stomata were larger when the plants were exposed to blue LEDs. The researchers concluded that blue LEDs might be beneficial for the stomatal opening of cotton plants.
Therefore, it is likely that the different light sources did not affect stomatal anatomy, as they did not alter the size or density of stomata during the growth and development of the seedlings. However, it is important to consider that exposure to different light sources may have influenced processes affecting the photosynthetic rate, such as stomatal opening and conductance, which could impact dry mass accumulation in the seedlings.

4. Conclusions

Blue LEDs and the red + blue LED combination, which resulted in greater dry mass accumulation in the seedlings, may be a promising alternative to fluorescent lamps for in vitro rooting of Marubakaido apple rootstocks. This would lead to more developed seedlings with a higher likelihood of survival during the acclimatization phase. Although red LEDs inhibit dry mass production compared to blue LEDs, they can still be used, as they produced similar dry mass levels to fluorescent lamps. Additionally, LEDs offer several advantages beyond their specific peaks within the favorable range for plants, such as high luminous efficiency, minimal heating, long lifespan, absence of heavy metals, and low energy consumption, enhancing profitability in in vitro plant propagation.
Fluorescent lamps induce a higher accumulation of chlorophylls and carotenoids compared to LEDs but result in lower dry mass production compared to blue LEDs and the red + blue LED combination in the in vitro rooting of Marubakaido apple rootstock seedlings.
Blue LEDs are more favorable than red LEDs and fluorescent lamps for dry mass accumulation in the in vitro rooting of Marubakaido apple rootstock seedlings.
Blue LEDs, red LEDs, and the red + blue LED combination can be used as alternatives to fluorescent lamps in the in vitro rooting of Marubakaido apple rootstock seedlings.
The different light sources used in the treatments do not affect the density and average area of stomata in M9 apple rootstock seedlings.

Author Contributions

.EMB and MSM conceived and coordinated this project; AMTS performed the experiments with the help of RLV, BS, ELS. EMB and MSM analyzed data and wrote the manuscript. All authors have read and approved the final version of the manuscript.

Institutional Review Board Statement

The study did not require ethical approval.

Informed Consent Statement

Not applicable. This study did not involve humans.

Data Availability Statement

The data that support the findings of this study are available upon request from the corresponding author.

Conflicts of Interest

The authors declare no conflicts of interest.

References

  1. Stanger, M.C.; Steffens, C.A.; Soethe, C.; Moreira, M.A.; do Amarante, C.V.T. Phenolic Content and Antioxidant Activity during the Development of ‘Brookfield’ and ‘Mishima’ Apples. J Agric Food Chem 2017, 65, 3453–3459. [Google Scholar] [CrossRef] [PubMed]
  2. Bueno, M.P.; Silva, A.C.; Nunes, A.L. de P.F.; Sardinha, A.C.; Lima, P.T. dos S.; Silva, J.F. Análise Da Comercialização Da Cadeia Produtiva Da Maçã Brasileira: Produção, Importação e Exportação No Período 2015 a 2019/ Analysis of the Commercialization of the Brazilian Apple Production Chain: Production, Import and Export in the Year 2015 to 2019. Brazilian Journal of Development 2021, 7, 34061–34078. [Google Scholar] [CrossRef]
  3. FAO FAOSTAT Crops and Livestock Production. FAOSTAT Analytical Brief 60 Agricultural production statistics 2000-2021 2021, 60.
  4. Purin, S.; Filho, O.K.; Stürmer, S.L. Mycorrhizae Activity and Diversity in Conventional and Organic Apple Orchards from Brazil. Soil Biol Biochem 2006, 38, 1831–1839. [Google Scholar] [CrossRef]
  5. Pertille, R.H.; Citadin, I.; Oliveira, L. de S. de; Broch, J. de C.; Kvitschal, M.V.; Araujo, L. The Influence of Temperature on the Phenology of Apple Trees Grown in Mild Winter Regions of Brazil, Based on Long-Term Records. Sci Hortic 2022, 305, 111354. [Google Scholar] [CrossRef]
  6. Mahmud, I.; Kousik, C.; Hassell, R.; Chowdhury, K.; Boroujerdi, A.F. NMR Spectroscopy Identifies Metabolites Translocated from Powdery Mildew Resistant Rootstocks to Susceptible Watermelon Scions. J Agric Food Chem 2015, 63, 8083–8091. [Google Scholar] [CrossRef] [PubMed]
  7. Orazem, P.; Stampar, F.; Hudina, M. Fruit Quality of Redhaven and Royal Glory Peach Cultivars on Seven Different Rootstocks. J Agric Food Chem 2011, 59, 9394–9401. [Google Scholar] [CrossRef]
  8. Jin, Z.; Sun, H.; Sun, T.; Wang, Q.; Yao, Y. Modifications of ‘Gold Finger’ Grape Berry Quality as Affected by the Different Rootstocks. J Agric Food Chem 2016, 64, 4189–4197. [Google Scholar] [CrossRef]
  9. Liu, X.; Li, J.; Huang, M.; Chen, J. Mechanisms for the Influence of Citrus Rootstocks on Fruit Size. J Agric Food Chem 2015, 63, 2618–2627. [Google Scholar] [CrossRef] [PubMed]
  10. de Macedo, T.A.; da Silva, P.S.; Sander, G.F.; Welter, J.F.; Rufato, L.; de Rossi, A. Productivity and Quality of “Fuji Suprema” Apple Fruit in Different Rootstocks and Growing Conditions. Sci Hortic 2019, 256, 108651. [Google Scholar] [CrossRef]
  11. Dolgov, S. V.; Hanke, M. Transgenic Temperate Fruit Tree Rootstocks. In Tree Transgenesis; Springer Berlin Heidelberg: Berlin, Heidelberg, 2006; pp. 335–350. [Google Scholar]
  12. Samad, A.; McNeil, D.L.; Khan, Z.U. Effect of Interstock Bridge Grafting (M9 Dwarfing Rootstock and Same Cultivar Cutting) on Vegetative Growth, Reproductive Growth and Carbohydrate Composition of Mature Apple Trees. Sci Hortic 1999, 79, 23–38. [Google Scholar] [CrossRef]
  13. Santos da Silva, P.; de Lima, J.M.; dos Santos, M.F.S.; Petry, D.; Rufato, L.; Nerbass, F.R.; Bogo, A. Performance of ‘Gala Select’ and ‘Fuji Suprema’ Grafted on Geneva Series Rootstocks under Fallow Land and Replanting Conditions in Southern Brazil. Heliyon 2023, 9, e22125. [Google Scholar] [CrossRef] [PubMed]
  14. Marini, R.P.; Fazio, G. Apple Rootstocks. In Horticultural Reviews; Wiley, 2018; pp. 197–312.
  15. Jones, O.P.; Hopgood, M.E.; O’Farrell, D. Propagation in Vitro of M.26 Apple Rootstocks. Journal of Horticultural Science 1977, 52, 235–238. [Google Scholar] [CrossRef]
  16. Dobránszki, J.; Teixeira da Silva, J.A. Micropropagation of Apple — A Review. Biotechnol Adv 2010, 28, 462–488. [Google Scholar] [CrossRef]
  17. Luiz de Oliveira, J.; Ramos Campos, E.V.; Fraceto, L.F. Recent Developments and Challenges for Nanoscale Formulation of Botanical Pesticides for Use in Sustainable Agriculture. J Agric Food Chem 2018, 66, 8898–8913. [Google Scholar] [CrossRef] [PubMed]
  18. Di Serio, M.G.; D’Ascenzo, D.; Giansante, L.; Del Re, P.; Bendini, A.; Casadei, E.; Gallina Toschi, T.; Mori, N.; Di Giacinto, L. Effect of Halyomorpha Halys Infestation on the Physicochemical Composition and Sensory Characteristics of Olive Fruits and Olive Oils. ACS Food Science & Technology 2024, 4, 821–832. [Google Scholar] [CrossRef]
  19. Naz, B.; Afzal, A.; Ali, H.; Ahmad, N.; Fazal, H.; Ullah, R.; Ali, E.A.; Ali, M.; Ullah, Z.; Ali, A.; et al. Melatonin-Induced Stress Enhanced Biomass and Production of High-Value Secondary Cell Products in Submerged Adventitious Root Cultures of Stevia Rebaudiana (Bert.). ACS Omega 2024. [CrossRef]
  20. Clemente, I.; Menicucci, F.; Colzi, I.; Sbraci, L.; Benelli, C.; Giordano, C.; Gonnelli, C.; Ristori, S.; Petruccelli, R. Unconventional and Sustainable Nanovectors for Phytohormone Delivery: Insights on Olea Europaea. ACS Sustain Chem Eng 2018, 6, 15022–15031. [Google Scholar] [CrossRef]
  21. Hussain, N.; Ali, H.; Mustafa, G.; Sarwar Khan, M.; Ali, B.; Ameer, S.; Zamir, S.; Iqbal, R.; Ali, B.; Khan, M.N.; et al. In Vitro Plant Regeneration from Petioles of Spinach ( Spinacia Oleracea L.). ACS Agricultural Science & Technology 2024, 4, 57–62. [Google Scholar] [CrossRef]
  22. Ma, X.; Gang, D.R. Metabolic Profiling of Turmeric ( Curcuma Longa L.) Plants Derived from in Vitro Micropropagation and Conventional Greenhouse Cultivation. J Agric Food Chem 2006, 54, 9573–9583. [Google Scholar] [CrossRef]
  23. Ashrafi, K.; Iqrar, S.; Saifi, M.; Khan, S.; Qamar, F.; Quadri, S.N.; Mishra, A.; Abdin, M.Z. Influence of Plant Growth Regulators on Glandular Trichome Density and Steviol Glycosides Accumulation in Stevia Rebaudiana. ACS Omega 2022, 7, 30967–30977. [Google Scholar] [CrossRef]
  24. Gulzar, B.; Mujib, A.; Qadir Malik, M.; Mamgain, J.; Syeed, R.; Zafar, N. Plant Tissue Culture: Agriculture and Industrial Applications. In Transgenic Technology Based Value Addition in Plant Biotechnology; Elsevier, 2020; pp. 25–49.
  25. Abdalla, N.; El-Ramady, H.; Seliem, M.K.; El-Mahrouk, M.E.; Taha, N.; Bayoumi, Y.; Shalaby, T.A.; Dobránszki, J. An Academic and Technical Overview on Plant Micropropagation Challenges. Horticulturae 2022, 8, 677. [Google Scholar] [CrossRef]
  26. Gutiérrez-Gamboa, G.; Alañón-Sánchez, N.; Mateluna-Cuadra, R.; Verdugo-Vásquez, N. An Overview about the Impacts of Agricultural Practices on Grape Nitrogen Composition: Current Research Approaches. Food Research International 2020, 136, 109477. [Google Scholar] [CrossRef] [PubMed]
  27. Moon, H.K.; Park, S.-Y.; Kim, Y.W.; Kim, C.S. Growth of Tsuru-Rindo (Tripterospermum Japonicum) Culturedin Vitro under Various Sources of Light-Emitting Diode (LED) Irradiation. Journal of Plant Biology 2006, 49, 174–179. [Google Scholar] [CrossRef]
  28. Dutta Gupta, S.; Jatothu, B. Fundamentals and Applications of Light-Emitting Diodes (LEDs) in in Vitro Plant Growth and Morphogenesis. Plant Biotechnol Rep 2013, 7, 211–220. [Google Scholar] [CrossRef]
  29. Sharma, A.; Hazarika, M.; Heisnam, P.; Pandey, H.; Devadas, V.S.; Wangsu, M.; Kartha, B.D. Factors Affecting Production, Nutrient Translocation Mechanisms, and LED Emitted Light in Growth of Microgreen Plants in Soilless Culture. ACS Agricultural Science & Technology 2023, 3, 701–719. [Google Scholar] [CrossRef]
  30. Sharma, A.; Pandey, H.; Nampoothiri Devadas, V.A.S.; Singh, D.; Kartha, B.D.; Wangsu, M. Regulations and Factors Affecting of Light Emitting Diodes Artificial Light in Crop Production under Soilless Culture. ACS Agricultural Science & Technology 2023, 3, 616–630. [Google Scholar] [CrossRef]
  31. Yeh, N.; Chung, J.-P. High-Brightness LEDs—Energy Efficient Lighting Sources and Their Potential in Indoor Plant Cultivation. Renewable and Sustainable Energy Reviews 2009, 13, 2175–2180. [Google Scholar] [CrossRef]
  32. SCHUERGER, A. Anatomical Features of Pepper Plants (Capsicum AnnuumL.) Grown under Red Light-Emitting Diodes Supplemented with Blue or Far-Red Light. Ann Bot 1997, 79, 273–282. [Google Scholar] [CrossRef]
  33. Geng, F.; Moran, R.; Day, M.; Halteman, W.; Zhang, D. In Vitro Shoot Proliferation of Apple Rootstocks ‘B.9’, ‘G.30’, and ‘G.41’ Grown under Red and Blue Light. HortScience 2015, 50, 430–433. [Google Scholar] [CrossRef]
  34. Lin, Y.; Li, J.; Li, B.; He, T.; Chun, Z. Effects of Light Quality on Growth and Development of Protocorm-like Bodies of Dendrobium Officinale in Vitro. Plant Cell, Tissue and Organ Culture (PCTOC) 2011, 105, 329–335. [Google Scholar] [CrossRef]
  35. Senger, H. THE EFFECT OF BLUE LIGHT ON PLANTS AND MICROORGANISMS. Photochem Photobiol 1982, 35, 911–920. [Google Scholar] [CrossRef]
  36. Li, H.; Xu, Z.; Tang, C. Effect of Light-Emitting Diodes on Growth and Morphogenesis of Upland Cotton (Gossypium Hirsutum L.) Plantlets in Vitro. Plant Cell, Tissue and Organ Culture (PCTOC) 2010, 103, 155–163. [Google Scholar] [CrossRef]
  37. Murashige, T.; Skoog, F. A Revised Medium for Rapid Growth and Bio Assays with Tobacco Tissue Cultures. Physiol Plant 1962, 15, 473–497. [Google Scholar] [CrossRef]
  38. Borges, E.M. Hypothesis Tests and Exploratory Analysis Using R Commander and Factoshiny. J Chem Educ 2023, 100, 267–278. [Google Scholar] [CrossRef]
  39. Navarro, D.J.; Foxcroft, D.R. Learning Statistics with Jamovi. Learning Statistics with Jamovi: A Tutorial for Psychology Students and Other Beginners 2022.
  40. Silva de Souza, R.; Borges, E.M. Teaching Descriptive Statistics and Hypothesis Tests Measuring Water Density. J Chem Educ 2023, 100, 4438–4448. [Google Scholar] [CrossRef]
  41. Marcel Borges, E. Data Visualization Using Boxplots: Comparison of Metalloid, Metal, and Nonmetal Chemical and Physical Properties. J Chem Educ 2023, 100, 2809–2817. [Google Scholar] [CrossRef]
  42. Love, J.; Selker, R.; Marsman, M.; Jamil, T.; Dropmann, D.; Verhagen, J.; Ly, A.; Gronau, Q.F.; Smíra, M.; Epskamp, S.; et al. JASP : Graphical Statistical Software for Common Statistical Designs. J Stat Softw 2019, 88. [Google Scholar] [CrossRef]
  43. Sequeira, C.A.; Borges, E.M. Enhancing Statistical Education in Chemistry and STEAM Using JAMOVI. Part 2. Comparing Dependent Groups and Principal Component Analysis (PCA). J Chem Educ 2024. [Google Scholar] [CrossRef]
  44. Tanaka, M.; Takamura, T.; Watanabe, H.; Endo, M.; Yanagi, T.; Okamoto, K. In Vitro Growth of Cymbidium Plantlets Cultured under Superbright Red and Blue Light-Emitting Diodes (LEDs). J Hortic Sci Biotechnol 1998, 73, 39–44. [Google Scholar] [CrossRef]
  45. Hiyama, A.; Takemiya, A.; Munemasa, S.; Okuma, E.; Sugiyama, N.; Tada, Y.; Murata, Y.; Shimazaki, K. Blue Light and CO2 Signals Converge to Regulate Light-Induced Stomatal Opening. Nat Commun 2017, 8, 1284. [Google Scholar] [CrossRef]
  46. Shin, K.S.; Murthy, H.N.; Heo, J.W.; Hahn, E.J.; Paek, K.Y. The Effect of Light Quality on the Growth and Development of in Vitro Cultured Doritaenopsis Plants. Acta Physiol Plant 2008, 30, 339–343. [Google Scholar] [CrossRef]
  47. Li, H.; Tang, C.; Xu, Z. The Effects of Different Light Qualities on Rapeseed (Brassica Napus L.) Plantlet Growth and Morphogenesis in Vitro. Sci Hortic 2013, 150, 117–124. [Google Scholar] [CrossRef]
  48. Murashige, T. Plant Propagation Through Tissue Cultures. Annu Rev Plant Physiol 1974, 25, 135–166. [Google Scholar] [CrossRef]
  49. Liu, M.; Xu, Z.; Guo, S.; Tang, C.; Liu, X.; Jao, X. Evaluation of Leaf Morphology, Structure and Biochemical Substance of Balloon Flower (Platycodon Grandiflorum (Jacq.) A. DC.) Plantlets in Vitro under Different Light Spectra. Sci Hortic 2014, 174, 112–118. [Google Scholar] [CrossRef]
  50. SÆBØ, A.; Krekling, T.; Appelgren, M. Light Quality Affects Photosynthesis and Leaf Anatomy of Birch Plantlets in Vitro. Plant Cell Tissue Organ Cult 1995, 41, 177–185. [Google Scholar] [CrossRef]
  51. Kim, S.-J.; Hahn, E.-J.; Heo, J.-W.; Paek, K.-Y. Effects of LEDs on Net Photosynthetic Rate, Growth and Leaf Stomata of Chrysanthemum Plantlets in Vitro. Sci Hortic 2004, 101, 143–151. [Google Scholar] [CrossRef]
  52. Chée, R. In Vitro Culture of Vitis: The Effects of Light Spectrum, Manganese Sulfate and Potassium Iodide on Morphogenesis. Plant Cell Tissue Organ Cult 1986, 7, 121–134. [Google Scholar] [CrossRef]
  53. Jao, R.-C.; Lai, C.-C.; Fang, W.; Chang, S.-F. Effects of Red Light on the Growth of Zantedeschia Plantlets in Vitro and Tuber Formation Using Light-Emitting Diodes. HortScience 2005, 40, 436–438. [Google Scholar] [CrossRef]
  54. Lindemann, I. da S.; Lang, G.H.; Dittgen, C.L.; Rombaldi, C.V.; Elias, M.C.; Vanier, N.L. Effects of Preharvest Desiccation Using Glufosinate-Ammonium on Quality Attributes of Freshly Harvested and Long-Term Stored Soybeans. ACS Agricultural Science & Technology 2021, 1, 312–321. [Google Scholar] [CrossRef]
  55. Righini, H.; Tedeschi, P.; Maietti, A.; Francioso, O.; Quintana, A.M.; Zuffi, V.; Ciurli, A.; Roberti, R. Enhanced Growth and Nutritional Properties of Radish Sprouts Using Extracts from Anabaena Minutissima and Sargassum Vulgare. ACS Agricultural Science & Technology 2024, 4, 700–710. [Google Scholar] [CrossRef]
  56. Eduardo da Silva, K.; Marcel Borges, E.; Crestani, I.; Dognini, J.; César de Jesus, P. Cold Extraction Process for Producing a Low-Alcohol Beer, International Pale Lager Style: Evaluation and Description of Flavors Using Electronic Tongue. Food Research International 2024, 190, 114598. [Google Scholar] [CrossRef] [PubMed]
  57. Borges, E.M.; Gelinski, J.M.L.N.; de Oliveira Souza, V.C.; Barbosa Jr., F.; Batista, B.L. Monitoring the Authenticity of Organic Rice via Chemometric Analysis of Elemental Data. Food Research International 2015, 77, 299–309. [Google Scholar] [CrossRef]
  58. Sidou, L.F.; Borges, E.M. Teaching Principal Component Analysis Using a Free and Open Source Software Program and Exercises Applying PCA to Real-World Examples. J Chem Educ 2020, 97, 1666–1676. [Google Scholar] [CrossRef]
  59. Borges, E.M. How to Select Equivalent and Complimentary Reversed Phase Liquid Chromatography Columns from Column Characterization Databases. Anal Chim Acta 2014, 807, 143–152. [Google Scholar] [CrossRef] [PubMed]
  60. Zhou, J.; Wang, Y.; Zuverza-Mena, N.; Dimkpa, C.O.; White, J.C. Copper-Based Materials as an Effective Strategy for Improving Drought Resistance in Soybean ( Glycine Max ) at the Reproductive Stage. ACS Agricultural Science & Technology 2024, 4, 735–746. [Google Scholar] [CrossRef]
  61. Datta Majumdar, T.; Ghosh, C.K.; Mukherjee, A. Dual Role of Copper Nanoparticles in Bacterial Leaf Blight-Infected Rice: A Therapeutic and Metabolic Approach. ACS Agricultural Science & Technology 2021, 1, 160–172. [Google Scholar] [CrossRef]
  62. Neo, D.C.J.; Ong, M.M.X.; Lee, Y.Y.; Teo, E.J.; Ong, Q.; Tanoto, H.; Xu, J.; Ong, K.S.; Suresh, V. Shaping and Tuning Lighting Conditions in Controlled Environment Agriculture: A Review. ACS Agricultural Science & Technology 2022, 2, 3–16. [Google Scholar] [CrossRef]
  63. Perea-Brenes, A.; Garcia, J.L.; Cantos, M.; Cotrino, J.; Gonzalez-Elipe, A.R.; Gomez-Ramirez, A.; Lopez-Santos, C. Germination and First Stages of Growth in Drought, Salinity, and Cold Stress Conditions of Plasma-Treated Barley Seeds. ACS Agricultural Science & Technology 2023, 3, 760–770. [Google Scholar] [CrossRef]
  64. Tang, C.; Zhang, X.; Zhao, Y.; Li, L.; Wei, J.; Yang, Z.; Chen, X.; Zheng, H.; Zhou, Z.; Tang, W.; et al. Response of Chlorosis and Growth to Light Intensity in Rice Seedlings. ACS Agricultural Science & Technology 2024, 4, 234–243. [Google Scholar] [CrossRef]
  65. Garg, V.K.; Gupta, R.; Kumar, R.; Gupta, R.K. Adsorption of Chromium from Aqueous Solution on Treated Sawdust. Bioresour Technol 2004, 92, 79–81. [Google Scholar] [CrossRef]
  66. Shrivastava, A.; Gupta, V. Methods for the Determination of Limit of Detection and Limit of Quantitation of the Analytical Methods. Chronicles of Young Scientists 2011, 2, 21. [Google Scholar] [CrossRef]
  67. Alvarenga, I.C.A.; Pacheco, F.V.; Silva, S.T.; Bertolucci, S.K.V.; Pinto, J.E.B.P. In Vitro Culture of Achillea Millefolium L.: Quality and Intensity of Light on Growth and Production of Volatiles. Plant Cell, Tissue and Organ Culture (PCTOC) 2015, 122, 299–308. [Google Scholar] [CrossRef]
Preprints 121956 g001
Figure 1. Seedlings of the Marubakaido apple rootstock cultivar obtained after 30 days of in vitro rooting under different light source.
Figure 1. Seedlings of the Marubakaido apple rootstock cultivar obtained after 30 days of in vitro rooting under different light source.
Preprints 121956 g001
Preprints 121956 g002
Figure 2. Boxplot of height of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Figure 2. Boxplot of height of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Preprints 121956 g002
Preprints 121956 g003
Figure 3. Boxplot of fresh mass of aerial part of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Figure 3. Boxplot of fresh mass of aerial part of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Preprints 121956 g003
Preprints 121956 g004
Figure 4. Boxplots of dry mass of aerial part (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Figure 4. Boxplots of dry mass of aerial part (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Preprints 121956 g004
Preprints 121956 g005
Figure 5. Boxplot of roots dry mass (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Figure 5. Boxplot of roots dry mass (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Preprints 121956 g005
Preprints 121956 g006
Figure 6. Boxplot of roots fresh mass (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Figure 6. Boxplot of roots fresh mass (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Preprints 121956 g006
Preprints 121956 g007
Figure 7. Boxplots of number of leaves in Marubakaido apple rootstock seedlings obtained using four independent treatments.
Figure 7. Boxplots of number of leaves in Marubakaido apple rootstock seedlings obtained using four independent treatments.
Preprints 121956 g007
Preprints 121956 g008
Figure 8. Boxplot of the number of roots fresh mass (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Figure 8. Boxplot of the number of roots fresh mass (mg) of Marubakaido apple rootstock seedlings obtained using four independent treatments.
Preprints 121956 g008
Preprints 121956 g009
Figure 9. Loading plot of the vegetative growth of seedlings of ‘Marubakaido’ apple tree rootstocks rooted in vitro under different sources of light.
Figure 9. Loading plot of the vegetative growth of seedlings of ‘Marubakaido’ apple tree rootstocks rooted in vitro under different sources of light.
Preprints 121956 g009
Preprints 121956 g010
Figure 10. Score plot of the vegetative growth of seedlings of ‘Marubakaido’ apple tree rootstocks rooted in vitro under different sources of light.
Figure 10. Score plot of the vegetative growth of seedlings of ‘Marubakaido’ apple tree rootstocks rooted in vitro under different sources of light.
Preprints 121956 g010
Preprints 121956 g011
Figure 11. Images obtained by optical microscopy of the abaxial surface of leaf samples from in vitro rooted seedlings of the M9 apple rootstock cultivar using LEDs and a fluorescent lamp.
Figure 11. Images obtained by optical microscopy of the abaxial surface of leaf samples from in vitro rooted seedlings of the M9 apple rootstock cultivar using LEDs and a fluorescent lamp.
Preprints 121956 g011
Table 1. MS medium composition.
Table 1. MS medium composition.
Stok solution Components Concentration in the stock solution (g L⁻¹) Final concentration in culture medium (g L⁻¹)
Macronutrients
A NH4NO3 33 1.65
B KNO3 38 1.9
C CaCl2.2H2O 8,8 0.44
D MgSO4.7H2O 7.4 0.37
E KH2PO4 3.4 0.17
Micronutrients4
F MnSO4.H2O 3.38 0.0169
H3BO3 1.24 0.0062
ZnSO4.7H2O 1.72 0.0086
Kl 0.166 0.00083
Na2MoO4.2H2O 0.05 0.00025
CuSO4.5H2O 0.005 0.000025
CoCl2.6H2O 0.005 0.000025
FeEDTA
G Na2EDTA.2H2O 3,7 0.0373
FeSO4.7H2O 2,78 0.0278
Vitamins and amino acids
H Thiamine.HCl 0.04 0.0002
Nicotinic acid 0.2 0.001
Pyridoxine.HCl 0.2 0.001
Glycine 0.8 0.004
- Myo-inositol - 0.1
Sucrose - 30
Table 2. Vegetative growth of seedlings of ‘Marubakaido’ apple tree rootstocks rooted in vitro under different sources of light.
Table 2. Vegetative growth of seedlings of ‘Marubakaido’ apple tree rootstocks rooted in vitro under different sources of light.
Tratamentos Height (cm) Number of leaves Number of roots Fresh mass (mg) Dry mass (mg)
Aerial parts roots Aerial parts Roots
Blue LED 1.54 ns 12.50 ns 7.45 ns 118 a 127ns 26 a 15 ns
Red LED 1.76 11.30 6.85 84 bc 100 18 bc 15
Red + Blue LED 1.39 12.05 4.80 100 ab 104 23 ab 15
Control 1.63 10.55 7.50 64 c 131 13 c 15
RSD (%) 17.8 14.2 26.5 18.9 17.7 18.7 16.2
Table 3. Tukey Post hoc test for the dry mass of aerial part (mg) obtianed for the four tratments.
Table 3. Tukey Post hoc test for the dry mass of aerial part (mg) obtianed for the four tratments.
Blue Red Red + Blue Red + Blue fluorescent
Blue p-value — 0.002 0.750 0.568 < .001
Red p-value — 0.877 0.402 0.018
Red + Blue p-value — 1.000 0.065
Red + Blue p-value — < .001
fluorescent p-value —
Note. * p < .05, ** p < .01, *** p < .001.
Table 4. Pairwise comparisons of Roots dry masses (mg) obtained using the four treatments.
Table 4. Pairwise comparisons of Roots dry masses (mg) obtained using the four treatments.
W p
Blue LED Control -3.37 0.080
Blue LED Red + Blue LED -1.62 0.660
Blue LED Red LED -3.81 0.036
Control Red + Blue LED 2.16 0.419
Control Red LED -1.20 0.831
Red + Blue LED Red LED -2.66 0.237
Table 5. Chlorophyll a, b, total (a + b) and carotenoids content in leaf samples of ‘Marubakaido’ apple tree rootstock seedlings rooted in vitro under different light sources.
Table 5. Chlorophyll a, b, total (a + b) and carotenoids content in leaf samples of ‘Marubakaido’ apple tree rootstock seedlings rooted in vitro under different light sources.
Treatments Chlorophyll a
(mg g-1)		 Chlorophyll b
(mg g-1)		 Total Chlorophyll (a+b)
(mg g-1) 		Carotenoids (mg g-1)
Blue LED 2.37b 0.54b 2.9b 0.74b
RED LED 2.49b 0.63b 3.12b 0.78b
Red+ Blue LED vermelho + azul 2.59b 0.62b 3.21b 0.79b
Control 3.17a 0.83a 3.99a 0.94a
RSD (%) 7.7 8.1 7.7 6.9
Means followed by the same letter in the column do not differ statistically according to Tukey's test at 5%.
Table 6. Density and mean area of stomata of the abaxial face of leaf samples of ‘M9’ apple tree rootstock seedlings rooted in vitro under different light sources.
Table 6. Density and mean area of stomata of the abaxial face of leaf samples of ‘M9’ apple tree rootstock seedlings rooted in vitro under different light sources.
Treatments Density
(stomata, mm-2)		 Area
(µm-2)
Blue LED 404.85 ns 377.8 ns
Red LED 322.76 453.94
Red+Blue LED 382.46 434.75
Control 317.16 438.27
RSD (%) 20.6 32.4
ns: not significant according to Tukey's test at 5%.
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.
Copyright: This open access article is published under a Creative Commons CC BY 4.0 license, which permit the free download, distribution, and reuse, provided that the author and preprint are cited in any reuse.
Prerpints.org logo

Preprints.org is a free preprint server supported by MDPI in Basel, Switzerland.

facebook logotwitter logolinkedin logo
MDPI Initiatives
Important Links
Subscribe

Disclaimer

Terms of Use

Privacy Policy

© 2024 MDPI (Basel, Switzerland) unless otherwise stated
