Therapeutic Options for Crigler-Najjar Syndrome: A Scoping Review

Altmetrics

Downloads

78

Views

42

Comments

0

A peer-reviewed article of this preprint also exists.

Submitted:

14 September 2024

Posted:

17 September 2024

You are already at the latest version

Alerts
Abstract
Crigler-Najjar Syndrome (CNS) is a rare genetic disorder caused by mutations in the UGT1A1 gene, leading to impaired bilirubin conjugation and severe unconjugated hyperbilirubinemia. CNS presents in two forms: CNS type 1 (CNS1), the more severe form with a complete absence of UGT1A1 activity, and CNS type 2 (CNS2), with partial enzyme activity. CNS1 requires aggressive management, including phototherapy and plasmapheresis, but liver transplantation (LT) remains the only definitive cure. The timing of LT is critical, as it must be performed before the onset of irreversible brain damage (kernicterus), making early intervention essential. However, LT poses risks such as graft rejection and lifelong immunosuppression. CNS2 is milder, with patients re-sponding well to phenobarbital and having a lower risk of kernicterus. Recent advancements in gene therapy and autologous hepatocyte transplantation offer promising alternatives to LT. Gene therapy using adeno-associated virus (AAV) vectors has shown potential in preclinical studies, though challenges remain in pediatric applications due to liver growth and pre-existing immunity. Autologous hepatocyte transplantation avoids the risks of rejection but requires further research. These emerging therapies provide hope for more effective and less invasive treatment options, aiming to improve the quality of life for CNS patients and reduce reliance on lifelong interven-tions.
Keywords:
Subject: Medicine and Pharmacology  -   Pediatrics, Perinatology and Child Health

1. Introduction

Crigler-Najjar syndrome (CNS) is a rare autosomal recessive disorder characterized by severe unconjugated hyperbilirubinemia. CNS results in nonhemolytic jaundice, with its most serious complication being bilirubin-induced neurologic dysfunction. This occurs when bilirubin crosses the blood-brain barrier and binds to specific brain tissues. CNS is associated with various mutations in the bilirubin uridine diphosphoglucuronate glucuronosyltransferase coding gene (bilirubin-UGT, also known as UGT1A1) [1].
Two forms of CNS are recognized based on the extent of UGT1A activity loss: type I disease (CNS1) is characterized by severe jaundice and a high risk of neurologic sequelae (kernicterus), resulting from the complete absence of enzymatic activity; type II disease (CNS2) is a milder form with decreased enzyme activity, lower serum bilirubin levels, and little to no risk of kernicterus [2].
Current therapeutic options for CNS include phototherapy, phenobarbital administration, and liver transplantation. Additional approaches include liver cell transplantation and gene therapy. This narrative review aims to summarize the existing knowledge about CNS, focusing on current therapeutic strategies and potential future treatments.
We reviewed the literature by searching the Medline database via the PubMed interface (https://pubmed.ncbi.nlm.nih.gov/®) and Google Scholar (https://scholar.google.com/), selecting articles published between January 2000 and January 2024. Case reports and clinical trials on standardized and experimental therapies were also collected to highlight currently available treatment options. The search utilized controlled vocabulary and key terms (MESH indexed: “Crigler-Najjar syndrome” and/or “Crigler Najjar syndrome”). Articles were selected based on predefined inclusion criteria: a) patient population (pediatric patients diagnosed with CNS); b) the primary focus of the article (pathogenesis, therapy, outcome, future perspectives); c) availability of relevant data within the article; d) publication period (2000-2024); e) human subjects; f) language (English). Exclusion criteria were: a) non-English language; b) lack of a full abstract; c) unsupported data; d) articles reporting novel mutations without a description of clinical or therapeutic implications. After the initial searches, 55 articles were chosen based on title and abstract screening. Of these, 30 studies specifically focused on CNS therapy were selected for their relevant content, which reported on CNS treatments and outcomes. Narrative reviews, studies reporting genetic mutations without phenotypic impact, and reports that combined data from both adult and pediatric patients without distinction were excluded. Additional sources cited within the selected articles were also reviewed, resulting in a total of 64 articles referenced in this systematic review. The cited articles are organized by title, location, study design, population, study objectives, summary of results, and conclusions.

2. Insights into Crigler-Najjar Syndrome (CNS)

2.1. Epidemiology

CNS is an extremely rare disorder, affecting approximately 0.6 to 1 in every 1 million newborns worldwide and fewer than 1 in 100,000 individuals in Europe [3]. Both sexes are equally affected, and the condition occurs across all ethnic groups. However, it is more prevalent in populations with a high frequency of UGT1A1 mutations due to a founder effect, such as the Old Order Amish and Mennonite communities, as well as among children born to consanguineous parents [4].

2.2. Genetics

CNS types I and II are caused by mutations in the UGT1A1 gene, located on chromosome 2q37, which result in impaired enzymatic activity. UGT proteins are divided into two families, UGT1 and UGT2, based on amino acid sequence similarity. The UGT1 family includes nine functional enzymes (UGT1A1 to UGT1A10) and four pseudogenes, all encoded by a single gene on chromosome 2q37. Each UGT1A isoform has a unique first exon, followed by exons 2 to 5 [5].
A related condition, Gilbert Syndrome (GS), is characterized by intermittent episodes of mild jaundice, with serum bilirubin levels usually below 3 mg/dL. In GS, UGT activity is reduced to about 30% of normal, leading to indirect hyperbilirubinemia. GS shares a genetic link with CNS1 and CSN2, as both conditions commonly involve the homozygous A(TA)7TAA polymorphism in the promoter of the UGT1A1 gene, referred to as UGT1A1*28 [6].
UGT1A1 is predominantly expressed in the liver, and genetic testing for UGT1A1 mutations is used to confirm diagnoses of GS, CNS2, or CNS1 in patients with persistent unconjugated hyperbilirubinemia without hemolysis. Identifying these patients is crucial for appropriate management, early treatment initiation, and for offering genetic counseling to family members [7].
The genotype-phenotype correlation is complex, as variations in enzyme activity may also result from genomic, transcriptional, translational, or post-translational changes. In CNS1, there is a complete loss of UGT1A1 activity due to deletions, insertions, missense mutations, or premature stop codons, resulting in severe unconjugated hyperbilirubinemia [8].
Most CNS2 patients have homozygous or compound heterozygous missense mutations, reducing enzyme activity to less than 10% of normal. This residual activity can often be enhanced with phenobarbital treatment [9]. Genetic studies have shown that chain-terminating mutations are more common in CNS1, while missense mutations are more frequent in CNS2 patients [7,10].
To investigate UGT1A1 mutations in GS and CNS2, Sun et al. studied 95 adult Chinese patients with hereditary unconjugated hyperbilirubinemia. Their analysis revealed 192 mutations across six sites. The most common mutation in GS was c.-3279T>G in the PBREM region (36.3%), followed by A(TA)7TAA (30.6%). In CNS2 patients, p.G71R was the most frequent mutation (38.2%), followed by c.-3279T>G and p.Y486D [10]. Similarly, Li et al. sequenced UGT1A1 in 11 unrelated Chinese CNS2 patients and found two cases with only a single heterozygous variant [11].
Given these findings, it is more accurate to refer to UGT1A1-associated diseases as a spectrum of conditions rather than distinct diagnoses, acknowledging variable penetrance and expressivity. Many cases with bilirubin levels and clinical features that fall between GS and CNS2 or between CNS-II and CNS-I have been reported [5,7,10,12].

2.3. Pathophysiology

Bilirubin is a product of heme degradation, with 80-90% derived from hemoglobin in senescent erythrocytes. Heme is broken down by heme oxygenase in the reticuloendothelial system, producing carbon monoxide and biliverdin in equal amounts. Biliverdin is then converted to bilirubin by biliverdin reductase. Bilirubin is transported to the liver, conjugated, and excreted in the bile. Gut bacteria convert conjugated bilirubin into urobilin and stercobilin.
CNS results from impaired bilirubin conjugation. In CNS1, unconjugated bilirubin levels typically range from 20-25 mg/dL but can reach as high as 50 mg/dL. Without UGT1A1 activity, bilirubin accumulates at a constant rate of 3.8 ± 0.6 mg/kg/day [13]. In CNS2, also known as Arias’ disease [14], UGT1A1 activity is reduced but not completely absent, leading to less severe hyperbilirubinemia, with levels below 20 mg/dL, though they can rise to 40 mg/dL during acute exacerbations [15].

2.4. Clinical Features

CNS1 presents with severe unconjugated hyperbilirubinemia beginning in the neonatal period and persisting throughout life. The primary complication is bilirubin-induced neurological dysfunction (BIND), particularly in the neonatal period [4]. Patients with CNS1 do not respond to phenobarbital and require long-term phototherapy to keep serum bilirubin levels within safe limits. CNS2 presents with varying phenotypes, and some patients maintain safe bilirubin levels without chronic treatment, while others may need phenobarbital or additional interventions during acute exacerbations triggered by infection, hemolysis, or biliary obstruction.
Jaundice in CNS usually appears when bilirubin levels exceed 5 mg/dL and is most easily visible in the fingerprint area, progressing in a cephalon-caudal pattern. Hyperbilirubinemia in CNS1 typically ranges from 10-25 mg/dL during the first 10 days of life, with an increased risk of neurological damage as bilirubin levels rise. Both total serum bilirubin (TSB) and the bilirubin/albumin ratio (B/A) are used to predict neurotoxicity. TSB ≥ 30 mg/dL and a B/A ratio ≥ 1.0 mol/mol are considered absolute thresholds for neurotoxicity [4].
If untreated, CNS can lead to acute bilirubin encephalopathy, kernicterus, or chronic bilirubin-induced neurological dysfunction (BIND), which manifests with symptoms like altered consciousness, abnormal tone, and impaired auditory responses [17]. Chronic bilirubin encephalopathy, or kernicterus, is characterized by choreoathetoid cerebral palsy, sensorineural hearing loss, palsy of vertical gaze, and dental enamel hypoplasia. BIND can occur in adolescence or adulthood, and a broader term, kernicterus spectrum disorder (KSD), has been proposed to unify diagnoses based on clinical and pathophysiologic criteria [18].
Historically, CNS was considered a condition with jaundice but without liver damage. However, recent reports suggest that hepatic fibrosis is present in 40-60% of patients undergoing liver transplantation, with fibrosis severity correlating with bilirubin concentration and age [19].

2.5. Quality of Life

The long-term impact of CNS on quality of life is not fully understood, but the burden of phototherapy is substantial for both patients and caregivers. For CNS1 patients, phototherapy requires whole-body exposure for 10-12 hours per day starting from birth [20]. Although it does not appear to interfere with circadian rhythms [21], it significantly restricts travel and social activities, imposing a heavy burden on patients and caregivers [22]. While liver transplantation is a definitive treatment, it comes with risks such as donor availability, potential graft failure, and the lifelong need for immunosuppressive drugs.

2.6. Pregnancy and Fetal Risks

Pregnancy in women with CNS is rare and presents unique challenges. The risk of fetal kernicterus and rising maternal bilirubin levels during pregnancy are major concerns. Unconjugated bilirubin crosses the placenta by passive diffusion, and in cases of elevated maternal bilirubin, the fetus is at risk for neurological complications and kernicterus [22]. Regular monitoring and adjusting phototherapy duration are recommended to maintain maternal bilirubin levels below 11.7 mg/dL, with a B/A ratio below 0.5 [23]. In CNS2 patients, combining phototherapy and phenobarbital can keep bilirubin levels within safe ranges [24]. Sequential treatment with phototherapy during the first trimester and phenobarbital in subsequent trimesters has been successfully used to manage bilirubin levels in pregnant women with CNS2 [25]. Hannam et al. reported on two infants born to women with CNS1. Both required exchange transfusions after birth, and one developed sensorineural hearing loss at seven months, despite phototherapy and albumin infusions during pregnancy [26].

3. Diagnosis of Crigler-Najjar Syndrome (CNS)

CNS should be suspected in any newborn with persistent jaundice and severe unconjugated hyperbilirubinemia, particularly after excluding common causes such as physiological jaundice, breast milk jaundice, polycythemia, systemic illness, and other inherited disorders of bilirubin metabolism [1]. Early recognition is crucial, as untreated CNS can lead to serious complications like kernicterus and long-term neurological damage.
The definitive diagnosis of CNS is made through molecular genetic testing for mutations in the UGT1A1 gene, which encodes the enzyme responsible for bilirubin conjugation. CNS can result from a variety of genetic abnormalities, including missense and nonsense mutations, insertions, deletions, and splicing abnormalities that affect any of the five exons of the UGT1A1 coding region. Therefore, it is important to sequence not only all exons but also the flanking intronic regions using Sanger sequencing or next-generation sequencing techniques. Additionally, sequencing the promoter region, particularly the TATAA box, is essential because the presence of a UGT1A1 polymorphism such as UGT1A128 (associated with GS) can further reduce the expression of the enzyme, exacerbating hyperbilirubinemia [1].
A key clinical feature distinguishing CNS1 from CNS2 is the serum bilirubin concentration. CNS2 typically presents with lower bilirubin levels than CNS1, although during acute exacerbations, the values can overlap. To aid in differentiating CNS2 from CNS1, a trial of phenobarbital therapy can be employed. In CNS2, phenobarbital typically lowers serum bilirubin levels by about 25%, while CNS1 patients show no significant response [1]. However, confirmation through genetic testing is required for a definitive diagnosis. CNS1 is associated with more severe mutations, including premature stop codons, frameshift mutations, or non-synonymous (missense) mutations that lead to the substitution of a single amino acid, resulting in the complete loss of UGT1A1 enzyme activity [1,27]. On the other hand, CNS2 is typically caused by missense mutations that reduce the enzyme's catalytic activity but do not abolish it entirely. If a patient with CNS2 also carries a Gilbert-type UGT1A128 promoter mutation, hyperbilirubinemia may be further aggravated due to decreased expression of the enzyme [1]. Historically, additional diagnostic methods included high-performance liquid chromatography (HPLC) or thin-layer chromatography of bile samples obtained from the duodenum. These tests were used to assess bilirubin conjugation patterns, although their role has diminished with the advent of advanced genetic testing [28].
In summary, a stepwise diagnostic approach for CNS includes the clinical assessment of jaundice, exclusion of other causes of hyperbilirubinemia, trial of phenobarbital in suspected CNS2 cases, and confirmation through comprehensive molecular genetic testing of the UGT1A1 gene. Early diagnosis and differentiation between CNS types are essential for guiding appropriate treatment and long-term management strategies.

4. Therapeutic Approach to Crigler-Najjar Syndrome (CNS)

Table 1 and Table 2 summarize the therapeutic strategies for CNS and the main published studies on treatment [29,30,31,32,33,34,35,36,37,38,39]. While phototherapy and phenobarbital remain the primary treatments for CNS, especially in CNS1 and CNS2, ongoing research into alternative therapies offers hope for improved management of the condition. Genetic analysis plays a critical role in guiding treatment decisions and tailoring therapies to individual patients, as CNS phenotypes can vary widely. However, liver transplantation remains the only definitive cure for CNS1, and early identification and management are essential to prevent complications like kernicterus.

4.1. Phototherapy

Phototherapy is the cornerstone of CNS treatment, particularly during infancy and childhood, and its introduction has significantly altered the disease's trajectory [29]. Phototherapy works by converting bilirubin IX-alpha-ZZ into its configurational isomers (such as lumirubin), which can then be excreted in bile without the need for conjugation [30]. Treatment should begin as soon as possible after birth, ideally following an exchange transfusion if required, and should be administered for an average of 12.4 ± 0.8 hours per day, including during the night.
To improve the effectiveness of night therapy, ursodeoxycholic acid (15–30 mg/kg/day) and a lipid-rich bedtime snack are recommended to stimulate bile flow and hepatic clearance of lumirubin. While various phototherapy systems provide high irradiance over large body surfaces, the therapy becomes less effective at puberty due to factors like skin thickening, increased pigmentation, and a reduced surface area-to-body mass ratio. During adolescence, bilirubin levels can reach dangerous levels, necessitating alternative or adjunctive therapies [4].
Patients with CNS2 have milder jaundice and can typically be treated with shorter phototherapy sessions, improving their quality of life. In contrast, CNS1 patients require immediate and sustained phototherapy to reduce the risk of kernicterus.

4.2. Phenobarbital

Phenobarbital is the first-line therapy for CNS2 patients, typically used to prevent acute increases in bilirubin levels during illness or stress. The drug induces UDPGT activity, enhancing bilirubin clearance by increasing hepatic uptake, storage, and excretion [31].
Chronic treatment is recommended for patients with serum bilirubin levels exceeding 15 mg/dL or for those experiencing significant jaundice that affects their quality of life. Standard doses are 2 mg/kg, 2-3 times per day in children, or 60-180 mg/day in adults, divided into two doses [7]. However, bilirubin levels may fluctuate, and responses to phenobarbital can vary among patients.
Some patients do not respond to phenobarbital. For example, Shi et al. [32] described a Bangladeshi patient with CNS2 who did not respond to phenobarbital (30 mg/day) despite having bilirubin levels typical of CNS2. Genetic analysis revealed heterozygous mutations, including an insertion in the HNF-1α site and a deletion in exon 1 of the UGT1A1 gene. The mutation in the HNF-1α binding site rendered the allele unresponsive to UGT1A1-inducing drugs, including phenobarbital. In such cases, confirming the presence of a mutated HNF-1α site should discourage the use of phenobarbital [32].
In contrast, Liu et al. [7] reported an unusual case of CNS in a Chinese boy with severe jaundice and kernicterus. Despite initial high bilirubin levels (40.4 mg/dL), the boy responded dramatically to phototherapy and phenobarbital, with serum bilirubin dropping to 5.4 mg/dL within days. Although his bilirubin levels suggested CNS1, his responsiveness to phenobarbital indicated CNS2, highlighting the importance of genetic analysis in confirming the diagnosis.
Gailite et al. [33] reported another interesting case of a 17-year-old male initially diagnosed with Gilbert Syndrome due to a homozygous UGT1A1 promoter polymorphism (A(TA)7TAA). However, after developing jaundice during puberty and responding to phenobarbital, the patient was reclassified as CNS2, despite having bilirubin levels consistent with CNS1. Genetic testing revealed four UGT1A1 variants, underscoring the importance of genotype-phenotype correlation for accurate classification and treatment decisions [33].
These cases highlight the variability of CNS phenotypes and the necessity of genetic testing for proper diagnosis and treatment planning.

4.3. Alternative Treatments

While there is no currently authorized medicinal product for the treatment of CNS, several alternative therapies have been investigated over the years.
Ihara et al. [34] followed a Japanese CNS1 patient from birth to age 19. After phototherapy became less effective at age 16, the patient was treated with plasmapheresis combined with an anion-exchange resin. This method removed approximately 98% of the daily bilirubin production, temporarily reducing bilirubin levels. However, its efficacy was inversely proportional to plasma volume, and the patient ultimately required a liver transplant at age 17 [34].
Schwegler et al. [35] reported a 17-year-old girl with CNS2 who showed a significant reduction in serum bilirubin levels after treatment with clofibrate. Building on this, Yilmaz et al. [36] conducted a trial in two CNS2 patients using fenofibrate (250 mg/day for one month). However, fenofibrate did not significantly reduce serum bilirubin levels (14.2 mg/dL pre-treatment vs. 14.5 mg/dL post-treatment).
Hafkamp et al. [37] conducted a randomized, placebo-controlled, double-blind, cross-over trial in 16 CNS patients to evaluate the effect of orlistat, a fat absorption inhibitor. Orlistat significantly reduced plasma unconjugated bilirubin concentrations (by approximately 43%) in 40% of the patients, particularly in those with lower dietary fat intake and BMI. However, the clinical response was not correlated with age, sex, CNS type, or co-treatments (phototherapy or phenobarbital).
A Cochrane review [38] examined the therapeutic potential of metalloporphyrins, which are heme analogs that inhibit heme oxygenase, the enzyme responsible for converting heme to bilirubin. Although some studies suggested that metalloporphyrins could lower plasma bilirubin levels and reduce the need for phototherapy, their use is limited due to adverse effects like photosensitivity and anemia. The review concluded that there is insufficient evidence to recommend metalloporphyrins as a routine treatment for neonatal unconjugated hyperbilirubinemia.

5. Liver Transplantation

Liver transplantation (LT) is currently the only definitive treatment for CNS1. When performed early, LT has shown excellent outcomes, significantly improving the quality of life and preventing the severe complications associated with the disease, such as kernicterus, with relatively few complications [20,40,41].
Three principal types LT are utilized to treat CNS1 patients: 1) Orthotopic Liver Transplantation (OLT), i.e. the most common approach, involves replacing the entire host liver with a whole or partial liver graft from a living or deceased donor; Auxiliary Liver Transplantation (ALT), i.e. a segment of the donor liver is transplanted, while the native liver is retained; Auxiliary Partial Orthotopic Liver Transplantation (APOLT), i.e. similar to ALT but involves transplanting only a partial liver graft alongside the patient’s own liver [42].
In CNS1, LT is usually recommended after the first year of life, particularly in adolescence, when phototherapy becomes less effective. As children grow, the increased body mass, thickening skin, and pigmentation decrease phototherapy efficiency, leading to longer hours under phototherapy lights, often during both day and night, which significantly impacts the patient's quality of life [42]. While LT offers a cure for CNS1 by providing a liver that can conjugate bilirubin, it is a highly invasive procedure with several limitations. These include the limited availability of suitable donors, the risk of graft rejection, and the need for life-long immunosuppression, which comes with associated risks like infections and malignancies. Thus, determining the optimal timing for LT is crucial—delaying it too long may result in irreversible neurological damage, while performing it too early increases exposure to the risks of surgery and immunosuppression.
Akdur et al. [43] reported on five pediatric CNS1 patients who underwent LT. They emphasized that OLT is curative for CNS1, with four of the five patients showing positive outcomes without neurological deficits. However, one patient, a 2-month-old infant, died post-OLT due to complications related to kernicterus. This infant, the youngest CNS1 patient to undergo LT, had undergone plasmapheresis due to extremely high bilirubin levels (30 mg/dL) and suspected bilirubin encephalopathy. Kernicterus developed post-transplant, leading to death, underscoring that once full-blown kernicterus develops, its effects may be irreversible even after transplantation [43,44]. This highlights the importance of initiating medical treatments such as plasmapheresis and phototherapy at the first signs of bilirubin encephalopathy and considering early LT to prevent further neurological damage.
Other reports also support early intervention. Tu et al. [45] described an 18-month-old child with CNS1 who underwent LT immediately after developing symptoms of kernicterus. The child's total bilirubin level had risen to 742.0 µmol/L before the operation, but post-transplant, bilirubin levels normalized, and mental function recovered without further signs of neurological damage. Schauer et al. [46] described three CNS1 patients aged 7, 12, and 4 years who underwent OLT before irreversible brain damage occurred. The 7-year-old exhibited early signs of brain injury (retardation) and had poor compliance with phototherapy. After LT, mental and physical development improved significantly. The 12-year-old had more advanced hyperbilirubinemia-related brain damage, with apathy, slurred speech, and impaired coordination, but these symptoms improved post-transplant. Although not fully recovered, the patient was able to attend school in the appropriate grade level. The 4-year-old, who showed no signs of neurological injury, had an excellent post-operative outcome, further underscoring the importance of early LT before severe neurological damage occurs.
In regions where cadaveric donor organs are scarce, living-related liver transplantation (LRLT) has become a viable alternative. Shurafa et al. [47] reported a case series of six CNS1 children from Saudi Arabia, three of whom underwent LRLT. In countries where CNS1 incidence is higher due to consanguineous marriages, LRLT is a critical option, providing a timely solution for patients awaiting transplantation. The outcomes in these cases were successful, demonstrating that LRLT can be an effective and reliable treatment option in countries with donor organ shortages.
Innovations such as split liver transplantation and domino transplantation are also being explored to increase the availability of donor organs. In 2002, Schauer et al. [48] reported the first case of simultaneous split liver transplantation in two brothers (aged 4 and 12) with CNS1, who received liver segments from the same donor. The younger brother, with no neurological deficits before surgery, had a completely uneventful recovery. The older brother, who had moderate brain damage (apathy, slurred speech, and reduced mental activity), showed significant improvement post-transplant, with enhanced mental and physical development as bilirubin levels normalized. Domino liver transplantation has been proposed as another option, particularly for certain non-cirrhotic metabolic liver diseases (NCMLD). Combining the APOLT technique with domino liver transplantation, where a CNS1 patient’s liver could be used as a donor for patients with NCMLD, offers an innovative strategy for treatment. Govil et al. described the first domino-auxiliary transplant case for a child with CNS1 who received a liver from a child with propionic acidemia, demonstrating the feasibility of this approach [49]. Dong et al. [50] also reported successful domino-APOLT in three CNS1 patients and described how the metabolic defect in the recipient’s liver was fully compensated by the donor liver.
While LT can successfully cure CNS1 by providing functional UGT1A1 enzyme activity, it is not without risks. Complications such as graft failure, portal vein thrombosis, and biliary stenosis have been reported. In one domino-APOLT case, a CNS1 patient developed portal vein thrombosis 2 days post-transplant, requiring reoperation, and later developed biliary stenosis that was successfully treated with percutaneous balloon dilatation [50]. Despite these risks, the metabolic defect in all cases was successfully corrected.
Overall, LT remains the only definitive cure for CNS1, offering a solution for patients who can no longer be managed with phototherapy or phenobarbital. The choice between orthotopic, auxiliary, or living-related liver transplantation depends on the availability of donor organs and the individual circumstances of the patient. Although LT carries risks such as graft rejection, life-long immunosuppression, and surgical complications, it has been shown to effectively prevent irreversible neurological damage and restore normal bilirubin metabolism, greatly improving patients' quality of life. Further advancements in transplant techniques, including domino and split liver transplants, offer hope for expanding donor organ availability and improving outcomes for CNS1 patients.

6. Liver Cell Transplantation

Liver cell transplantation (LCT) is a novel and less invasive therapeutic approach for treating CNS, particularly CNS1. LCT was first experimented with in Gunn rats, where isolated normal hepatocytes were introduced into the portal venous system, allowing these cells to integrate into the liver and become part of the hepatic cords [51]. Studies demonstrated that normalization of bilirubin levels in the Gunn rat model could be achieved with only 12% of the total liver mass expressing functional UGT1A1 [52]. This suggests that small amounts of transplanted liver tissue in humans can alleviate the underlying metabolic deficiency.
In CNS1 patients, LCT involves the transplantation of donor hepatocytes expressing functional UGT1A1 into the liver, with immunosuppressive therapy to prevent rejection. The less invasive nature of LCT offers advantages over whole-liver transplantation (LT), but the procedure has challenges, including the limited availability of cryopreserved hepatocytes and technical difficulties in ensuring adequate cell engraftment. Additionally, the transplanted cells typically function for only 6 to 9 months, making the treatment a temporary solution rather than a permanent cure [53]. Ongoing research is needed to optimize cell survival and long-term engraftment to improve the efficacy of LCT.
The first human LCT was performed in 1997 on a 5-year-old boy with ornithine transcarbamylase deficiency. In this case, splenic transplantation of adult hepatocytes helped control hyperammonemia and correct the metabolic defect temporarily, serving as a bridge to liver transplantation [54]. The following year, Fox et al. [55] treated a 10-year-old girl with CNS1 using LCT, which resulted in lowered bilirubin levels and reduced phototherapy needs. This was attributed to increased UGT1A1 activity, reaching up to 5.5% of normal enzyme function.
In a case series by Quaglia et al. [56], seven children with metabolic disorders underwent LCT, including a 1-year-old CNS1 patient who received 4.34 billion hepatocytes through the inferior mesenteric vein. This resulted in a 50% reduction in bilirubin levels and decreased phototherapy requirements. However, the effect diminished after 7 months, and the patient eventually underwent liver transplantation. Similar reports in the literature have shown that LCT can improve the quality of life in CNS1 patients by lowering bilirubin levels and reducing the time required for phototherapy [56].
Dhawan et al. [57] described two CNS1 patients (18 months old and 3 years old) who experienced a 50% and 30% reduction in serum bilirubin levels, respectively, following LCT. These cases further emphasize LCT's role in temporarily managing hyperbilirubinemia and delaying the need for liver transplantation.
More recently, Ribes-Koninckx et al. [58] presented data from four pediatric patients with different metabolic disorders who received hepatocyte transplantation with cryopreserved human hepatocytes. This study demonstrated the safety and efficacy of LCT as a bridge to LT, with one 7-month-old CNS1 patient showing a significant improvement in both neurological status and bilirubin levels. Despite severe jaundice and neurological symptoms (spasticity and axial hypotonia) due to kernicterus, LCT stabilized bilirubin levels at less than 50% of the initial values and reduced phototherapy from 24 to 12 hours per day. Furthermore, neuroradiological improvements were noted on magnetic resonance imaging, and the patient’s clinical status significantly improved, showing the potential for LCT to enhance neurological outcomes.
In another recent study, Jorns et al. [59] reported on two CNS1 patients who underwent liver resection followed by LCT. The initial liver resection served as a regenerative stimulus, leading to a transient increase in hepatocyte growth factor, which facilitated the engraftment of transplanted hepatocytes. This dual approach, combining partial hepatectomy and LCT, reduced serum bilirubin by over 50% and delayed the need for liver transplantation by 580 and 951 days, respectively. These are the longest reported survival times without LT in CNS1 patients treated with LCT. However, the loss of graft function was temporally associated with the emergence of donor-specific antibodies (DSAs), highlighting the need for further research to assess the impact of DSAs on hepatocyte engraftment and the long-term success of this approach.
As shown in Table 3, 14 CNS1 patients worldwide have undergone LCT, with 71% of them using this therapy as a bridge to liver transplantation [22,55,56,57,58,59,60,61,62,63]. LT was performed 4 to 31 months after the last LCT procedure [55]. Despite promising outcomes, LCT is still regarded primarily as a temporary measure to delay LT rather than a definitive treatment. The procedure offers a less invasive alternative that can significantly improve the quality of life and extend the period before liver transplantation is needed. However, further studies are required to enhance the long-term survival of transplanted hepatocytes and to evaluate the full potential of LCT in CNS1 treatment.

7. Gene Therapy

CNS is an ideal target for gene therapy because it is a monogenic disorder caused by mutations in the UGT1A1 gene, leading to the inability to conjugate bilirubin. Since the liver is the primary site of UGT1A1 expression and has a fenestrated endothelium, it allows easy access for gene transfer vectors through the bloodstream [1]. Over the last few decades, significant research has been conducted to identify the most effective vectors for applying gene therapy to CNS, primarily using the Gunn rat model [64]. The Gunn rat is a natural mutant that lacks UGT1A1 activity, making it an excellent model for studying CNS.
Recombinant adeno-associated virus (AAV) vectors have emerged as the most promising tools for gene replacement therapy, particularly in liver disorders like CNS. These vectors are favored because of their high safety profile and ability to effectively deliver genetic material [65]. AAV-mediated gene therapy is especially promising for adult patients, but it faces challenges in pediatric and juvenile patients due to the possibility of vector dilution in a growing liver, where hepatocyte proliferation can dilute the effects of the therapy [20]. Another challenge is the pre-existing immunity in some patients who have developed antibodies against the viral capsid, which can reduce the effectiveness of the therapy. As a result, researchers are actively exploring immunomodulatory strategies to overcome this barrier. In 2006, Seppen et al. [64] compared the efficiency of various AAV serotypes in the transduction of rat hepatocytes. Their study showed that AAV1 vectors were the most efficient in correcting UGT1A1 deficiency in vivo. The level of UGT1A1 correction achieved would be therapeutic in humans. However, the study also found large macroscopic lipid lesions of uncertain origin in all AAV-treated animals, which raised concerns about potential side effects. More recently, in 2018, Collaud et al. [66] conducted preclinical studies using an AAV8 vector carrying the human UGT1A1 transgene (AAV8-hUGT1A1) under the control of a liver-specific promoter. The results demonstrated long-term safety and efficacy in correcting the UGT1A1 deficiency in animal models, supporting the translation of this therapy to clinical trials. Toxicology and biodistribution studies confirmed that the AAV8-hUGT1A1 vector is well-tolerated and effective over time, paving the way for clinical application in humans.
Currently, two clinical trials are underway to evaluate gene transfer via recombinant viral vectors in CNS1 patients (clinicaltrials.gov: NCT03466463 and NCT03223194). These trials represent a significant step forward in the potential treatment of CNS1 using gene therapy.
Another potential approach to gene therapy is the transplantation of autologous hepatocytes that have been genetically corrected ex vivo. This strategy could serve as an alternative to full liver transplantation. Birraux et al. [67,68] proposed a novel ex vivo gene therapy technique called "SLIT" (Selective Liver Infusion Therapy). This process involves the isolation of hepatocytes from the patient, genetic correction via transduction with an HIV-1-derived lentiviral vector carrying the hUGT1A1 transgene, and subsequent transplantation back into the patient. Lentiviral vectors are advantageous because they integrate into the genome of target cells and can transduce terminally differentiated cells, allowing for long-term therapeutic correction.
In preclinical studies, hepatocytes isolated from a CNS1 patient were successfully transduced with lentiviral vectors encoding the hUGT1A1 gene. Following transplantation into immunodeficient mice, the corrected hepatocytes engrafted long-term (up to 26 weeks) and expressed the therapeutic protein. This study suggests that ex vivo gene therapy using lentiviral vectors could offer a permanent solution for CNS1 patients by providing a renewable source of corrected hepatocytes, potentially circumventing the need for liver transplantation.
In conclusion, gene therapy offers a promising approach to treating Crigler-Najjar Syndrome, particularly for patients who cannot undergo liver transplantation or as an alternative to lifelong phototherapy. Advances in AAV-mediated gene delivery, immunomodulatory strategies, and ex vivo gene correction using lentiviral vectors are bringing gene therapy closer to clinical reality for CNS1. While challenges remain, including vector dilution in growing livers and pre-existing immunity, ongoing clinical trials and research efforts are laying the groundwork for a future where CNS1 can be effectively treated with gene therapy.

8. Conclusions

CNS consists of two forms: CNS1 and CNS2, both caused by mutations in the UGT1A1 gene. CNS1 is the more severe form, characterized by a complete absence of UGT1A1 activity, leading to extreme unconjugated hyperbilirubinemia and a high risk of irreversible brain damage (kernicterus). Treatments like phototherapy and plasmapheresis are only temporary, and LT remains the only definitive cure. The timing of LT is critical and must occur before neurological damage, though balancing early intervention with the risks of surgery and lifelong immunosuppression is challenging. Alternative transplantation methods such as living donor or domino transplantation offer potential solutions to donor shortages.
CNS2 is milder, with some residual enzyme activity, and patients typically respond well to phenobarbital and occasional phototherapy, with LT rarely needed. CNS2 patients usually have a better prognosis and quality of life compared to CNS1.
Future directions include gene therapy, which holds promise for correcting the underlying genetic defect, particularly in CNS1, though challenges like vector dilution and immune responses must be overcome. Autologous hepatocyte transplantation offers another alternative, avoiding the complications of organ rejection. As the understanding of CNS continues to evolve, the goal is to offer CNS1 and CNS2 patients therapies that not only extend life but also improve its quality by minimizing the burden of lifelong treatments and preventing irreversible neurological damage.

Author Contributions

V.S. and S.L. wrote the first draft of the manuscriot; S.L. and M.M. performed the literature review; S.E. revised the first draft and gave a substantial scientific contribution. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Institutional Review Board Statement

Not applicable for a review article.

Informed Consent Statement

Not applicable for a review article.

Data Availability Statement

Not applicable for a review article.

Acknowledgments

We would like Giuseppe Indolfi from University of Florence, Florence, Italy, for is support in the first phases of this manuscript.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. Kadakol, A.; Ghosh, S.S.; Sappal, B.S.; Sharma, G.; Chowdhury, J.R.; Chowdhury, N.R. Genetic lesions of bilirubin uridine-diphosphoglucuronate glucuronosyltransferase (UGT1A1) causing Crigler-Najjar and Gilbert syndromes: correlation of genotype to phenotype. Hum Mutat. 2000 Oct;16, 297-306. [CrossRef] [PubMed]
  2. CRIGLER, J.F.; NAJJAR, V.A. Congenital familial nonhemolytic jaundice with kernicterus. Pediatrics. 1952 Aug;10, 169–180. [PubMed]
  3. Ebrahimi, A.; Rahim, F. Crigler-Najjar Syndrome: Current Perspectives and the Application of Clinical Genetics. Endocr Metab Immune Disord Drug Targets. 2018;18, 201-211. [CrossRef] [PubMed]
  4. Strauss, K.A.; Ahlfors, C.E.; Soltys, K.; Mazareigos, G.V.; Young, M.; Bowser, L.E.; Fox, M.D.; Squires, J.E.; McKiernan, P.; Brigatti, K.W.; Puffenberger, E.G.; Carson, V.J.; Vreman, H.J. Crigler-Najjar Syndrome Type 1: Pathophysiology, Natural History, and Therapeutic Frontier. Hepatology. 2020 Jun;71, 1923-1939. [CrossRef] [PubMed] [PubMed Central]
  5. Zheng, B.; Hu, G.; Yu, J.; Liu, Z. Crigler-Najjar syndrome type II in a Chinese boy resulting from three mutations in the bilirubin uridine 5'-diphosphate-glucuronosyltransferase (UGT1A1) gene and a family genetic analysis. BMC Pediatr. 2014 Oct 15;14:267. [CrossRef] [PubMed] [PubMed Central]
  6. Fretzayas, A.; Moustaki, M.; Liapi, O.; Karpathios, T. Gilbert syndrome. Eur J Pediatr. 2012 Jan;171, 11–15. [CrossRef] [PubMed]
  7. Liu, W.L.; Li, F.; He, Z.X.; Jiang, H.Y.; Ai, R.; Chen, X.X.; Huang, K. Analysis of bilirubin UDP-glucuronosyltransferase gene mutations in an unusual Crigler-Najjar syndrome patient. Mol Med Rep. 2012 Sep;6, 667–669. [CrossRef] [PubMed]
  8. Bosma, P.J.; Seppen, J.; Goldhoorn, B.; Bakker, C.; Oude Elferink, R.P.; Chowdhury, J.R.; Chowdhury, N.R.; Jansen, P.L. Bilirubin UDP-glucuronosyltransferase 1 is the only relevant bilirubin glucuronidating isoform in man. J Biol Chem. 1994 Jul 8;269, 17960–17964. Erratum in: J Biol Chem 1994 Oct 14;269, 2542. [PubMed]
  9. Aono, S.; Yamada, Y.; Keino, H.; Hanada, N.; Nakagawa, T.; Sasaoka, Y.; Yazawa, T.; Sato, H.; Koiwai, O. Identification of defect in the genes for bilirubin UDP-glucuronosyl-transferase in a patient with Crigler-Najjar syndrome type II. Biochem Biophys Res Commun. 1993 Dec 30;197, 1239–1244. [CrossRef] [PubMed]
  10. Sun, L.; Li, M.; Zhang, L.; Teng, X.; Chen, X.; Zhou, X.; Ma, Z.; Qi, L.; Wang, P. Differences in UGT1A1 gene mutations and pathological liver changes between Chinese patients with Gilbert syndrome and Crigler-Najjar syndrome type II. Medicine (Baltimore). 2017 Nov;96, e8620. [CrossRef] [PubMed] [PubMed Central]
  11. Li, L.; Deng, G.; Tang, Y.; Mao, Q. Spectrum of UGT1A1 Variations in Chinese Patients with Crigler-Najjar Syndrome Type II. PLoS One. 2015 May 20;10, e0126263. [CrossRef] [PubMed]
  12. Moyer, A.M.; Skierka, J.M.; Kotzer, K.E.; Kluge, M.L.; Black, J.L.; Baudhuin, L.M. Clinical UGT1A1 Genetic Analysis in Pediatric Patients: Experience of a Reference Laboratory. Mol Diagn Ther. 2017 Jun;21, 327-335. [CrossRef] [PubMed]
  13. Berk, P.D.; Howe, R.B.; Bloomer, J.R.; Berlin, N.I. Studies of bilirubin kinetics in normal adults. J Clin Invest. 1969 Nov;48, 2176–2190. [CrossRef] [PubMed] [PubMed Central]
  14. ARIASIM Chronic unconjugated hyperbilirubinemia without overt signs of hemolysis in adolescents and adults. J Clin Invest. 1962 Dec;41, 2233–2245. [CrossRef] [PubMed] [PubMed Central]
  15. Gollan, J.L.; Huang, S.N.; Billing, B.; Sherlock, S. Prolonged survival in three brothers with severe type 2 Crigler-Najjar syndrome. Ultrastructural and metabolic studies. Gastroenterology. 1975 Jun;68, 1543–1555. [PubMed]
  16. Iskander, I.; Gamaleldin, R.; El Houchi, S.; El Shenawy, A.; Seoud, I.; El Gharbawi, N.; Abou-Youssef, H.; Aravkin, A.; Wennberg, R.P. Serum bilirubin and bilirubin/albumin ratio as predictors of bilirubin encephalopathy. Pediatrics. 2014 Nov;134, e1330-9. [CrossRef] [PubMed] [PubMed Central]
  17. Ahlfors, C.E.; Wennberg, R.P.; Ostrow, J.D.; Tiribelli, C. Unbound (free) bilirubin: improving the paradigm for evaluating neonatal jaundice. Clin Chem. 2009 Jul;55, 1288–1299. [CrossRef] [PubMed]
  18. Le Pichon, J.B.; Riordan, S.M.; Watchko, J.; Shapiro, S.M. The Neurological Sequelae of Neonatal Hyperbilirubinemia: Definitions, Diagnosis and Treatment of the Kernicterus Spectrum Disorders (KSDs). Curr Pediatr Rev. 2017;13, 199-209. [CrossRef] [PubMed]
  19. Mitchell, E.; Ranganathan, S.; McKiernan, P.; Squires, R.H.; Strauss, K.; Soltys, K.; Mazariegos, G.; Squires, J.E. Hepatic Parenchymal Injury in Crigler-Najjar Type I. J Pediatr Gastroenterol Nutr. 2018 Apr;66, 588-594. [CrossRef] [PubMed]
  20. Bortolussi, G., & Muro, A. F. (2018). Advances in understanding disease mechanisms and potential treatments for Crigler–Najjar syndrome. Expert Opinion on Orphan Drugs, 6(7), 425–439. [CrossRef]
  21. Stebelova, K.; Kosnacova, J.; Zeman, M. Intense blue light therapy during the night-time does not suppress the rhythmic melatonin biosynthesis in a young boy. Endocr Regul. 2017 Jan 1;51, 31-34. [CrossRef] [PubMed]
  22. Dhawan, A.; Lawlor, M.W.; Mazariegos, G.V.; McKiernan, P.; Squires, J.E.; Strauss, K.A.; Gupta, D.; James, E.; Prasad, S. Disease burden of Crigler-Najjar syndrome: Systematic review and future perspectives. J Gastroenterol Hepatol. 2020 Apr;35, 530-543. [CrossRef] [PubMed]
  23. Wilson, J.H.; Sinaasappel, M.; Lotgering, F.K.; Langendonk, J.G. Recommendations for pregnancies in patients with crigler-najjar syndrome. JIMD Rep. 2013;7:59-62. [CrossRef] [PubMed]
  24. Passuello, V.; Puhl, A.G.; Wirth, S.; Steiner, E.; Skala, C.; Koelbl, H.; Kohlschmidt, N. Pregnancy outcome in maternal Crigler-Najjar syndrome type II: a case report and systematic review of the literature. Fetal Diagn Ther. 2009;26, 121–126. [CrossRef] [PubMed]
  25. Ito, T.; Katagiri, C.; Ikeno, S.; Takahashi, H.; Nagata, N.; Terakawa, N. Phenobarbital following phototherapy for Crigler-Najjar syndrome type II with good fetal outcome: a case report. J Obstet Gynaecol Res. 2001 Feb;27, 33–35. [CrossRef] [PubMed]
  26. Hannam, S.; Moriaty, P.; O'Reilly, H.; Craig, J.S.; Heneghan, M.A.; Baker, A.; Dhawan, A. Normal neurological outcome in two infants treated with exchange transfusions born to mothers with Crigler-Najjar Type 1 disorder. Eur J Pediatr. 2009 Apr;168, 427–429. [CrossRef] [PubMed]
  27. Clarke, D.J.; Moghrabi, N.; Monaghan, G.; Cassidy, A.; Boxer, M.; Hume, R.; Burchell, B. Genetic defects of the UDP-glucuronosyltransferase-1 (UGT1) gene that cause familial non-haemolytic unconjugated hyperbilirubinaemias. Clin Chim Acta. 1997 Oct 9;266, 63-74. [CrossRef] [PubMed]
  28. Lee, W.S.; McKiernan, P.J.; Beath, S.V.; Preece, M.A.; Baty, D.; Kelly, D.A.; Burchell, B.; Clarke, D.J. Bile bilirubin pigment analysis in disorders of bilirubin metabolism in early infancy. Arch Dis Child. 2001 Jul;85, 38-42. [CrossRef] [PubMed]
  29. CREMERRJ; PERRYMANPW; RICHARDSDH Influence of light on the hyperbilirubinaemia of infants. Lancet. 1958 May 24;1, 1094–1097. [CrossRef] [PubMed]
  30. Itoh, S.; Onishi, S. Kinetic study of the photochemical changes of (ZZ)-bilirubin IX alpha bound to human serum albumin. Demonstration of (EZ)-bilirubin IX alpha as an intermediate in photochemical changes from (ZZ)-bilirubin IX alpha to (EZ)-cyclobilirubin IX alpha. Biochem J. 1985 Feb 15;226, 251–258. [CrossRef] [PubMed]
  31. Ostrow, J.D. Therapeutic amelioration of jaundice: old and new strategies. Hepatology. 1988 May-Jun;8, 683–689. [CrossRef] [PubMed]
  32. Shi, X.; Aronson, S.; Khan, A.S.; Bosma, P.J. A novel UGT1A1 gene mutation causing severe unconjugated hyperbilirubinemia: a case report. BMC Pediatr. 2019 May 29;19, 173. [CrossRef] [PubMed]
  33. Gailite, L.; Rots, D.; Pukite, I.; Cernevska, G.; Kreile, M. Case report: multiple UGT1A1 gene variants in a patient with Crigler-Najjar syndrome. BMC Pediatr. 2018 Oct 3;18, 317. [CrossRef] [PubMed]
  34. Ihara, H.; Shino, Y.; Hashizume, N.; Shimizu, N.; Aoki, T.; Yoshida, M. Removal of protein-bound and unbound unconjugated bilirubin by perfusion of plasma through an anion-exchange resin in a case of Crigler-Najjar syndrome type I. Ann Clin Biochem. 2003 Sep;40(Pt 5):528-33. [CrossRef] [PubMed]
  35. Schwegler, U.; May, B.; Müller, K.M. Crigler-Najjar-Syndrom Typ II bei einem 17jährigen Mädchen [Crigler-Najjar syndrome type II in a 17-year-old girl]. Z Gastroenterol. 1993 Feb;31 Suppl 2:83-4. German. [PubMed]
  36. Yilmaz, S.; Dursun, M.; Canoruç, F.; Kidir, V.; Beştaş, R. Fenofibrate treatment in two adults with Crigler-Najjar syndrome type II. Turk J Gastroenterol. 2006 Mar;17, 62–65. [PubMed]
  37. Hafkamp, A.M.; Nelisse-Haak, R.; Sinaasappel, M.; Oude Elferink, R.P.; Verkade, H.J. Orlistat treatment of unconjugated hyperbilirubinemia in Crigler-Najjar disease: a randomized controlled trial. Pediatr Res. 2007 Dec;62, 725–730. [CrossRef] [PubMed]
  38. Suresh, G.; Martin, C.L.; Soll, R. Metalloporphyrins for treatment of unconjugated hyperbilirubinemia in neonates. Cochrane Database of Systematic Reviews 2003, Issue 1. Art. No.: CD004207. [CrossRef]
  39. Aono, S.; Yamada, Y.; Keino, H.; Hanada, N.; Nakagawa, T.; Sasaoka, Y.; Yazawa, T.; Sato, H.; Koiwai, O. Identification of defect in the genes for bilirubin UDP-glucuronosyl-transferase in a patient with Crigler-Najjar syndrome type II. Biochem Biophys Res Commun. 1993 Dec 30;197, 1239–1244. [CrossRef] [PubMed]
  40. van der Veere CN, Sinaasappel M, McDonagh AF, Rosenthal P, Labrune P, Odièvre M, Fevery J, Otte JB, McClean P, Bürk G, Masakowski V, Sperl W, Mowat AP, Vergani GM, Heller K, Wilson JP, Shepherd R, Jansen PL. Current therapy for Crigler-Najjar syndrome type 1: report of a world registry. Hepatology. 1996 Aug;24, 311–315. [CrossRef] [PubMed]
  41. Fagiuoli, S.; Daina, E.; D'Antiga, L.; Colledan, M.; Remuzzi, G. Monogenic diseases that can be cured by liver transplantation. J Hepatol. 2013 Sep;59, 595-612. [CrossRef] [PubMed]
  42. Ambrosino, G.; Varotto, S.; Strom, S.C.; Guariso, G.; Franchin, E.; Miotto, D.; Caenazzo, L.; Basso, S.; Carraro, P.; Valente, M.L.; D'Amico, D.; Zancan, L.; D'Antiga, L. Isolated hepatocyte transplantation for Crigler-Najjar syndrome type 1. Cell Transplant. 2005;14(2-3):151-7. [CrossRef] [PubMed]
  43. Akdur, A.; Kirnap, M.; Ayvazoglu Soy, E.H.; Ozcay, F.; Moray, G.; Arslan, G.; Haberal, M. Unusual Indications for a Liver Transplant: A Single-Center Experience. Exp Clin Transplant. 2017 Feb;15(Suppl 1):128-132. [CrossRef] [PubMed]
  44. Ozçay, F.; Alehan, F.; Sevmiş, S.; Karakayali, H.; Moray, G.; Torgay, A.; Arslan, G.; Haberal, M. Living related liver transplantation in Crigler-Najjar syndrome type 1. Transplant Proc. 2009 Sep;41, 2875–2877. [CrossRef] [PubMed]
  45. Tu, Z.H.; Shang, D.S.; Jiang, J.C.; Zhang, W.; Zhang, M.; Wang, W.L.; Lou, H.Y.; Zheng, S.S. Liver transplantation in Crigler-Najjar syndrome type I disease. Hepatobiliary Pancreat Dis Int. 2012 Oct;11, 545–548. [CrossRef] [PubMed]
  46. Schauer, R.; Stangl, M.; Lang, T.; Zimmermann, A.; Chouker, A.; Gerbes, A.L.; Schildberg, F.W.; Rau, H.G. Treatment of Crigler-Najjar type 1 disease: relevance of early liver transplantation. J Pediatr Surg. 2003 Aug;38, 1227–1231. [CrossRef] [PubMed]
  47. Al Shurafa, H.; Wali, S.; Chehab, M.S.; Al Shahed, M.; Jawdat, M.; Djurberg, H.; Bassas, A. Living-related liver transplantation for Crigler-Najjar syndrome in Saudi Arabia. Clin Transplant. 2002 Jun;16, 222–226. [CrossRef] [PubMed]
  48. Schauer, R.; Lang, T.; Zimmermann, A.; Stangl, M.; Da Silva, L.; Schildberg, F.W.; Rau, H.G. Successful liver transplantation of two brothers with crigler-najjar syndrome type 1 using a single cadaveric organ. Transplantation. 2002 Jan 15;73, 67–69. [CrossRef] [PubMed]
  49. Govil, S.; Shanmugam, N.P.; Reddy, M.S.; Narasimhan, G.; Rela, M. A metabolic chimera: Two defective genotypes make a normal phenotype. Liver Transpl. 2015 Nov;21, 1453–1454. [CrossRef] [PubMed]
  50. Dong, C.; Song, Z.; Meng, X.; Sun, C.; Wang, K.; Yang, Y.; Qin, H.; Han, C.; Zhang, F.; Zheng, W.; Gao, W. Successful living donor liver transplantation plus domino-auxiliary partial orthotopic liver transplantation for pediatric patients with metabolic disorders. Pediatr Surg Int. 2020 Dec;36, 1443-1450. [CrossRef] [PubMed]
  51. Matas, A.J.; Sutherland, D.E.; Steffes, M.W.; Mauer, S.M.; Sowe, A.; Simmons, R.L.; Najarian, J.S. Hepatocellular transplantation for metabolic deficiencies: decrease of plasms bilirubin in Gunn rats. Science. 1976 May 28;192, 892–894. [CrossRef] [PubMed]
  52. Asonuma, K.; Gilbert, J.C.; Stein, J.E.; Takeda, T.; Vacanti, J.P. Quantitation of transplanted hepatic mass necessary to cure the Gunn rat model of hyperbilirubinemia. J Pediatr Surg. 1992 Mar;27, 298-301. [CrossRef] [PubMed]
  53. Muraca, M.; Ferraresso, C.; Vilei, M.T.; Granato, A.; Quarta, M.; Cozzi, E.; Rugge, M.; Pauwelyn, K.A.; Caruso, M.; Avital, I.; Inderbitzin, D.; Demetriou, A.A.; Forbes, S.J.; Realdi, G. Liver repopulation with bone marrow derived cells improves the metabolic disorder in the Gunn rat. Gut. 2007 Dec;56, 1725–1735. [CrossRef] [PubMed]
  54. Strom, S.C.; Fisher, R.A.; Thompson, M.T.; Sanyal, A.J.; Cole, P.E.; Ham, J.M.; Posner, M.P. Hepatocyte transplantation as a bridge to orthotopic liver transplantation in terminal liver failure. Transplantation. 1997 Feb 27;63, 559–569. [CrossRef] [PubMed]
  55. Fox, I.J.; Chowdhury, J.R.; Kaufman, S.S.; Goertzen, T.C.; Chowdhury, N.R.; Warkentin, P.I.; Dorko, K.; Sauter, B.V.; Strom, S.C. Treatment of the Crigler-Najjar syndrome type I with hepatocyte transplantation. N Engl J Med. 1998 May 14;338, 1422–1426. [CrossRef] [PubMed]
  56. Quaglia, A.; Lehec, S.C.; Hughes, R.D.; Mitry, R.R.; Knisely, A.S.; Devereaux, S.; Richards, J.; Rela, M.; Heaton, N.D.; Portmann, B.C.; Dhawan, A. Liver after hepatocyte transplantation for liver-based metabolic disorders in children. Cell Transplant. 2008;17, 1403–1414. [CrossRef] [PubMed]
  57. Dhawan, A.; Mitry, R.R.; Hughes, R.D. Hepatocyte transplantation for liver-based metabolic disorders. J Inherit Metab Dis. 2006 Apr-Jun;29(2-3):431-5. [CrossRef] [PubMed]
  58. Ribes-Koninckx C, Ibars EP, Calzado Agrasot MÁ, Bonora-Centelles A, Miquel BP, Vila Carbó JJ, Aliaga ED, Pallardó JM, Gómez-Lechón MJ, Castell JV. Clinical outcome of hepatocyte transplantation in four pediatric patients with inherited metabolic diseases. Cell Transplant. 2012;21, 2267–2282. [CrossRef] [PubMed]
  59. Jorns, C.; Nowak, G.; Nemeth, A.; Zemack, H.; Mörk, L.M.; Johansson, H.; Gramignoli, R.; Watanabe, M.; Karadagi, A.; Alheim, M.; Hauzenberger, D.; van Dijk, R.; Bosma, P.J.; Ebbesen, F.; Szakos, A.; Fischler, B.; Strom, S.; Ellis, E.; Ericzon, B.G. De Novo Donor-Specific HLA Antibody Formation in Two Patients With Crigler-Najjar Syndrome Type I Following Human Hepatocyte Transplantation With Partial Hepatectomy Preconditioning. Am J Transplant. 2016 Mar;16, 1021–1030. [CrossRef] [PubMed]
  60. Allen, K.J.; Buck, N.E.; Williamson, R. Stem cells for the treatment of liver disease. Transpl Immunol. 2005 Dec;15, 99-112. [CrossRef] [PubMed]
  61. Stéphenne, X.; Vosters, O.; Najimi, M.; Beuneu, C.; Dung, K.N.; Wijns, W.; Goldman, M.; Sokal, E.M. Tissue factor-dependent procoagulant activity of isolated human hepatocytes: relevance to liver cell transplantation. Liver Transpl. 2007 Apr;13, 599-606. Erratum in: Liver Transpl. 2007 Jul;13, 1070. [CrossRef] [PubMed]
  62. Khan, A.A.; Parveen, N.; Mahaboob, V.S.; Rajendraprasad, A.; Ravindraprakash, H.R.; Venkateswarlu, J.; Rao, P.; Pande, G.; Narusu, M.L.; Khaja, M.N.; Pramila, R.; Habeeb, A.; Habibullah, C.M. Treatment of Crigler-Najjar Syndrome type 1 by hepatic progenitor cell transplantation: a simple procedure for management of hyperbilirubinemia. Transplant Proc. 2008 May;40, 1148–1150. [CrossRef] [PubMed]
  63. Lysy, P.A.; Najimi, M.; Stephenne, X.; Bourgois, A.; Smets, F.; Sokal, E.M. Liver cell transplantation for Crigler-Najjar syndrome type I: update and perspectives. World J Gastroenterol. 2008 Jun 14;14, 3464–3470. [CrossRef] [PubMed]
  64. Seppen, J.; Bakker, C.; de Jong, B.; Kunne, C.; van den Oever, K.; Vandenberghe, K.; de Waart, R.; Twisk, J.; Bosma, P. Adeno-associated virus vector serotypes mediate sustained correction of bilirubin UDP glucuronosyltransferase deficiency in rats. Mol Ther. 2006 Jun;13, 1085–1092. [CrossRef] [PubMed]
  65. Junge, N.; Mingozzi, F.; Ott, M.; Baumann, U. Adeno-associated virus vector-based gene therapy for monogenetic metabolic diseases of the liver. J Pediatr Gastroenterol Nutr. 2015 Apr;60, 433–440. [CrossRef] [PubMed]
  66. Collaud, F.; Bortolussi, G.; Guianvarc'h, L.; Aronson, S.J.; Bordet, T.; Veron, P.; Charles, S.; Vidal, P.; Sola, M.S.; Rundwasser, S.; Dufour, D.G.; Lacoste, F.; Luc, C.; Wittenberghe, L.V.; Martin, S.; Le Bec, C.; Bosma, P.J.; Muro, A.F.; Ronzitti, G.; Hebben, M.; Mingozzi, F. Preclinical Development of an AAV8-hUGT1A1 Vector for the Treatment of Crigler-Najjar Syndrome. Mol Ther Methods Clin Dev. 2018 Dec 31;12:157-174. [CrossRef] [PubMed]
  67. Nguyen, T.H.; Birraux, J.; Wildhaber, B.; Myara, A.; Trivin, F.; Le Coultre, C.; Trono, D.; Chardot, C. Ex vivo lentivirus transduction and immediate transplantation of uncultured hepatocytes for treating hyperbilirubinemic Gunn rat. Transplantation. 2006 Sep 27;82, 794-803. [CrossRef] [PubMed]
  68. Birraux, J.; Menzel, O.; Wildhaber, B.; Jond, C.; Nguyen, T.H.; Chardot, C. A step toward liver gene therapy: efficient correction of the genetic defect of hepatocytes isolated from a patient with Crigler-Najjar syndrome type 1 with lentiviral vectors. Transplantation. 2009 Apr 15;87, 1006–1012. [CrossRef] [PubMed]
Table 1. Therapeutic strategies for Crigler-Najjar syndrome (CNS).
Table 1. Therapeutic strategies for Crigler-Najjar syndrome (CNS).
Treatment Indication Duration/dose Efficacy
Phototherapy Soon after birth 12.4 ± 0.8 hours Temporary, most patients need daily cycles
Phenobarbital First-line therapy in CNS2 patients 2 mg/kg/dose 2-3 times per day Good response if taken lifelong
Orlistat CNS1, CNS2 33-66 mg/m2 during meals for 4-6 weeks Patients with lower dietary fat intake and low body mass index
Mesoporphyrin CNS1, CNS2 Mesoporphyrin in a single dose of six micromoles per kilogram body
weight, given intramuscularly		 Lower plasma bilirubin level, lower frequency of severe hyperbilirubinemia, decreased need for phototherapy, shorter duration of hospitalization
Table 2. Therapeutic strategies in the main published studies.
Table 2. Therapeutic strategies in the main published studies.
Article Study population Diagnosis Treatment: first and second line Outcome
Ihara et al. [34] 19-year-old Japanese
man with CNS1 		CNS1 diagnosed on liver biopsy (total absence of enzymatic activity) and at the age of 15y sequencing UGT gene -Phototherapy (>10h every night) from few days of life to 16y
-Plasmapheresis
done with an anion-exchange
resin (bilirubin-adsorbent
column) from 16y, for 6 month, 2 times/week (duration: 3h)		 Plasma perfusion could barely remove plasma the
Bilirubin synthesized
Each day.
At 17y the patient received liver transplantation
Yilmaz et al. [36] 15-year-old male CNS2 -Phenobarbital (2 mg/kg/day) for 3 days p.o. produced 27% decrease in indirect bilirubin level
- Fenofibrate (250 mg/day os) for 1 month		 At the end of treatment with fenofibrate serum indirect bilirubin was found to be unchanged
Hafkamp et al. [37] 16 patients (paediatric > 7 years old and adult) 7 CNS1, 9 CNS2 Adults: 60-120 mg during meals; Children: 33-66 mg/m2 during meals The decrease was clinically relevant (more than 10% decrease) in 6 patients (40%)
Shi et al. [32] A 14-year-old female patient from Bangladesh CNS2 Heterozygous for two different UGT1A1 mutations:
1) 3 nucleotide insertion in the HNF-1α binding site
2) 2 nucleotide deletion in exon 1 of UGT1A1 gene (novel) results in a premature stop codon 		Not responsive to treatment with phenobarbital
Strauss et al. [4] 20 patients diagnosed by sequencing the UGTA1A gene
19 patients had CNS1 phenotype (8 moths to 21 yo)		 17 patients (Amish or Mennonite descent) homozygous for a 222C→A mutation in exon 1 of UGT1A1 that resulted in a stop codon (Y74X) and complete absence of transferase activity Continuous high-intensity phototherapy.
Four patients treated with orthotopic liver transplantation		 A systematic approach to neonatal screening, light dosing, and kernicterus prevention can assure that children and adults proceed to transplantation in good neurological health
Liu et al. [7] 4-month-old Chinese boy Compound heterozygous mutations: a missense mutation c.211G>A (p.G71R) in the first exon and a synonymous mutation c.1470C>T (p.D490D)
in the fifth exon		 Phototherapy (66 hrs) for 7 days and phenobarbital (5 mg/kg/day) for 3 days Followed until 4 months of age, no more treatment needed
Gailite et al. [33] 17-year-old Caucasian male Four different variants in the UGT1A1 gene: g.3664A > C; g.4963_4964TA; g.5884G > T; g.11895_11898del Phenobarbital The rs3755319 variant explains neonatal hyperbilirubinemia, the A(TA)7TAA the hyperbilirubinemia, and two other variants are reported in a compound heterozygous state in patients with CNS2
Suresh et al. [38] 84 cases
86 controls (from three single center studies) 		Neonatal unconjugated hyperbilirubinemia Mesporphyrin in a single dose of six micromoles per kilogram body
weight, given intramuscularly		 lower plasma bilirubin level, lower frequency of severe hyperbilirubinemia, decreased need for phototherapy, shorter duration of hospitalization
Crigler-Najjar syndrome (CNS).
Table 3. Studies reporting liver cell transplantation (LCT).
Table 3. Studies reporting liver cell transplantation (LCT).
Reference study Age/weight at LCT Hepatocytes transplanted Decrease in bilirubin Final outcome
Fox et al. [55] 10 y / 37 kg 7.5×109 (0.2×109/kg) 50% LT after 4 years
Darwish et al. [57] 8 y / NA 7.5x109 (NA) 40% LT after 20 months
Allen et al. [60] 7 y / 23 kg 1.4x109 (0.06x109/kg) 40% LT after 11 months
Ambrosino et al. [42] 9 y / 30 kg 7.5x109 (0.25x109/kg) 50% LT after 5 months
Dhawan et al. [22] 18 m / NA 4.3x109 (NA) 50% LT after 8 months
3 y / 7 kg 2.1x109 (0.29x109/kg) 30% LT not performed
Stéphenne et al. [61] 9 m / NA NA (033x109/kg) NA NA
Khan et al. [62] 2 y / NA 0.015x109 (NA) NA NA
Quuaglia et al. [56] 1 y / NA 4.34x109 (NA) NA LT after 6 months
Lysy et al. [63] 9 y / 38 kg 6x109 (0.16x109/kg) 35% LT after 6 months
1 y /7.4 kg 2.6x109 (0.35x109/kg) 65% LT after 4 months
Ribes-Koninckx et al. [58] 7 m / NA 6.7x109 (NA) NA LT not performed
Jorns et al. [59] 13 y 11.2x109 50% LT after 19 months
11 y 5.3x109 50% LT after 31 months
Liver transplant (LT); not available (NA).
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.
Copyright: This open access article is published under a Creative Commons CC BY 4.0 license, which permit the free download, distribution, and reuse, provided that the author and preprint are cited in any reuse.
Prerpints.org logo

Preprints.org is a free preprint server supported by MDPI in Basel, Switzerland.

facebook logotwitter logolinkedin logo
MDPI Initiatives
Important Links
Subscribe

Disclaimer

Terms of Use

Privacy Policy

© 2024 MDPI (Basel, Switzerland) unless otherwise stated
